EC 1 12DC/4A S-C
EC 1 12DC/4A S-C 3000757 PHOENIX CONTACT Electronic device circuit breaker
$0.00USD
4643 in stock
Key Specifications
GTIN:4046356708500
Note:Made to Order (non-returnable)
Orderkey:3000757
Packing unit:10 pc
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4046356708500 |
| Note | Made to Order (non-returnable) |
| Orderkey | 3000757 |
| Packing unit | 10 pc |
| Width (General) | 12.5 mm |
| Height (General) | 80 mm |
| Country of origin | DE (Germany) |
| (Connection data) | For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
| Custom tariff number | 85362010 |
| Color (Key Commercial Data) | black |
| China RoHS (Connection data) | Environmentally Friendly Use Period = 50 |
| REACh SVHC (Connection data) | Lead 7439-92-1 |
| Screw thread (Ambient conditions) | M4 |
| Mounting type (Key Commercial Data) | DIN rail: 35 mm |
| Weight per Piece (excluding packing) | 70.000 g |
| Stripping length (Ambient conditions) | 10 mm |
| Connection method (Ambient conditions) | Screw connection |
| Number of positions (Key Commercial Data) | 1 |
| Tightening torque max (Ambient conditions) | 1.8 Nm |
| Tightening torque, min (Ambient conditions) | 1.5 Nm |
| Ambient temperature (operation) (Dimensions) | -20 °C ... 60 °C (ordinary locations) |
| Conductor cross section solid max. (Ambient conditions) | 10 mm² |
| Conductor cross section solid min. (Ambient conditions) | 0.5 mm² |
| Conductor cross section flexible max. (Ambient conditions) | 10 mm² |
| Conductor cross section flexible min. (Ambient conditions) | 0.5 mm² |
| 2 conductors with same cross section, solid max. (Ambient conditions) | 4 mm² |
| 2 conductors with same cross section, solid min. (Ambient conditions) | 0.5 mm² |
| 2 conductors with same cross section, stranded max. (Ambient conditions) | 4 mm² |
| 2 conductors with same cross section, stranded min. (Ambient conditions) | 0.5 mm² |
Product Description
Electronic protection switch, ON/OFF control input, rated current: 4 A
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
