ZS-XPM2
ZS-XPM2 ZS 0011H 177223 OMRON Expansion Frame Mount Adapter
$242.28USD
81 in stock
Key Specifications
(Specifications & ordering info):Order code
DC (Specifications & ordering info):NPN
1 m (Specifications & ordering info):ZX-XC1A
4 m (Specifications & ordering info):ZX-XC4A
Supplier Information
OMRON
Products: 41472
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| (Specifications & ordering info) | Order code |
| DC (Specifications & ordering info) | NPN |
| 1 m (Specifications & ordering info) | ZX-XC1A |
| 4 m (Specifications & ordering info) | ZX-XC4A |
| 8 m (Specifications & ordering info) | ZX-XC8A |
| PNP (Specifications & ordering info) | ZX-TDA41 |
| Item (Specifications & ordering info) | ZX-TDS01T |
| Name (Specifications & ordering info) | Order code |
| Size (Specifications & ordering info) | Type |
| 6 dia. (Specifications & ordering info) | Short type |
| 8 dia. (Specifications & ordering info) | Standard type |
| Remarks (Specifications & ordering info) | Order code |
| Function (Specifications & ordering info) | Measurement value displaypresent value/set value/output value displayDisplay reverseECO modenumber of display digit changesSample holdpeak holdbottom hold, peak-to-peak holdSelf-peak holdself-bottom holdzero resetInitial resetdirect threshold value settingposition teachingHysteresis width settingtiming inputsreset inputJudgement output hold inputmonitor focus(A-B) calculations6(A+B) calculations (see note 4.)sensor disconnection detectionZero reset memoryfunction locknon-measurement settingClamp value settingscale inversionzero reset indicatorSpan adjustmentwarming-up displaypressing force alarm |
| ZX-TDS_T (Specifications & ordering info) | |
| Materials (Specifications & ordering info) | Sensor head |
| Indicators (Specifications & ordering info) | Judgement indicators: High (orange), pass (green), low (yellow), 7-segment main digital display (red), 7-segment sub-digitaldisplay (yellow), power ON (green), zero reset (green), enable (green) |
| Linearity8 (Specifications & ordering info) | ±0.3% F.S. |
| Accessories (Specifications & ordering info) | Instruction manual, preamplifier mounting brackets (ZX-XBT1) |
| Resolution7 (Specifications & ordering info) | 0.1 µm |
| Cable length (Specifications & ordering info) | Order code |
| Power supply (Specifications & ordering info) | Output type |
| Preamplifier (Specifications & ordering info) | Polycarbonate |
| Air lift type (Specifications & ordering info) | ZX-TDS10T-V |
| Low-load type (Specifications & ordering info) | ZX-TDS04T-L |
| Standard type (Specifications & ordering info) | 4 mm |
| Linear output4 (Specifications & ordering info) | Current output: 4 to 20 mA/F.S., max. load resistance: 300 ΩVoltage output: ±4 V (±5 V, 1 to 5 V5), output impedance: 100 Ω |
| Type (material) (Specifications & ordering info) | Screw section |
| Ambient humidity (Specifications & ordering info) | Operating and storage: 35% to 85% (with no icing or condensation) |
| Ball type (ruby) (Specifications & ordering info) | Female screwM2.5x0.45 |
| Calculating unit (Specifications & ordering info) | ZX-CAL2 |
| Operating force9 (Specifications & ordering info) | Approx. 0.7 N |
| Ball type (steel) (Specifications & ordering info) | Female screwM2.5x0.45 |
| Connection method (Specifications & ordering info) | Prewired (standard cable length: 2 m) |
| Measurement range (Specifications & ordering info) | 1 mm |
| Measurement period (Specifications & ordering info) | 1 ms |
| Ambient temperature (Specifications & ordering info) | Operating: 0 to 50°C, storage:-15 to 60°C (with no icing or condensation) |
| Current consumption (Specifications & ordering info) | 140 mA max. (with sensor connected), for 24-VDC power supply voltage: 140 mA max. (with sensor connected) |
| Flat(carbide steel) (Specifications & ordering info) | Male screwM2.5x0.45 |
| Ultra-low-load type (Specifications & ordering info) | ZX-TDS10T-L |
| Power supply voltage (Specifications & ordering info) | 12 to 24 VDC±10%, ripple (p-p): 10% max. |
| Mechanical durability (Specifications & ordering info) | 10,000,000 operations min. |
| Weight (packed state) (Specifications & ordering info) | Approx. 100 g |
| Air lift/air push type (Specifications & ordering info) | ZX-TDS10T-VL |
| For DIN track mounting (Specifications & ordering info) | ZX-XBT2 |
| Ball type(carbide steel) (Specifications & ordering info) | Female screwM2.5x0.45 |
| Needle type(carbide steel) (Specifications & ordering info) | Male screwM2.5x0.45 |
| Temperature characteristic (Specifications & ordering info) | 0.03% F.S./°C |
| Attached to each sensor head (Specifications & ordering info) | ZX-XBT1 |
| Temperature characteristic10 (Specifications & ordering info) | Sensor head |
| Maximum actuator travel distance (Specifications & ordering info) | Approx. 1.5 mm |
| Possible average count settings3 (Specifications & ordering info) | 1, 16, 32, 64, 128, 256, 512, or 1,024 |
| Degree of protection (sensor head) (Specifications & ordering info) | IEC60529, IP67 |
| Conversion adapter(stainless steel) (Specifications & ordering info) | Through-hole female screwM2.5x0.45 |
| ZX-series communications interface unit (Specifications & ordering info) | ZX-SF11 |
| Judgement outputs(3 outputs: HIGH/PASS/LOW) (Specifications & ordering info) | NPN open-collector outputs, 30 VDC, 30 mA max.Residual voltage: 1.2 V max. |
| ZX-series sensor setup and logging software (CD-ROM) (Specifications & ordering info) | ZX-SW11EV31 |
| ZX-series communications interface unit+ setup software (CD-ROM) (Specifications & ordering info) | ZX-SFW11EV31,2 |
| Zero reset input, timing input, reset input, judgement output hold input (Specifications & ordering info) | ON: Short-circuited with 0-V terminal or 1.5 V or lessOFF: Open (leakage current: 0.1 mA max.) |
Product Description
Expansion frame mount adapter
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Size
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
