WS02-CFSC1-EV3-UP
WS02-CFSC1-EV3-UP NEW21020R 354914 OMRON Upgrade to V3.30 DeviceNet Security Network Configurator
$247.50USD
71 in stock
Key Specifications
Appearance (Specifications & ordering info):Appearance description
Input type (Specifications & ordering info):Sinking inputs (PNP)
ON voltage (Specifications & ordering info):11 VDC min. between each input terminal and G1
OFF current (Specifications & ordering info):1 mA max.
Supplier Information
OMRON
Products: 41472
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Appearance (Specifications & ordering info) | Appearance description |
| Input type (Specifications & ordering info) | Sinking inputs (PNP) |
| ON voltage (Specifications & ordering info) | 11 VDC min. between each input terminal and G1 |
| OFF current (Specifications & ordering info) | 1 mA max. |
| OFF voltage (Specifications & ordering info) | 5 VDC max. between each input terminal and G1 |
| Output type (Specifications & ordering info) | Sourcing outputs (PNP) |
| Input current (Specifications & ordering info) | 4.5 mA |
| Network router (Specifications & ordering info) | Ethernet/IP - DeviceNet router |
| Mounting method (Specifications & ordering info) | 35-mm DIN track |
| Residual voltage (Specifications & ordering info) | 1.2 V max. between each output terminal and V1 |
| Consumptioncurrent (Specifications & ordering info) | Communications power supply |
| Programming console (Specifications & ordering info) | CF-Card slot to store configurationUSB-Interface for maintenanceTouchscreen for easy troubleshooting |
| Degree of protection (Specifications & ordering info) | IP20 (IEC 60529) |
| Rated output current (Specifications & ordering info) | 0.7 A max. per output (see note.) |
| Safety networkcontroller (Specifications & ordering info) | 16 PNP inputs8 PNP outputs4 test outputs254 function block programmingremovable cage clamp terminals |
| Unit power supply voltage (Specifications & ordering info) | 20.4 to 26.4 VDC(24 VDC -15% +10%) |
| Safety networkconfigurator (Specifications & ordering info) | Installation disk (CD-ROM)IBM PC/AT compatibleWindows 2000, Windows XP, Windows 7 |
| Ambient storage temperature (Specifications & ordering info) | -40 to 70°C |
| Ambient operating temperature (Specifications & ordering info) | -10 to 55°C |
| Internal circuit power supply (Specifications & ordering info) | 24 VDC, 230 mA |
| Ethernet/IP andDeviceNet safety (Specifications & ordering info) | NE1A-SCPU02-EIP |
| DeviceNet communications power supply voltage (Specifications & ordering info) | 11 to 25 VDC(supplied from communications connector) |
| 40 PNP inputs8 PNP outputs8 test outputs254 function block programmingremovable cage clamp terminals (Specifications & ordering info) | USB andDeviceNet safety |
Product Description
Upgrade to V3.30 DeviceNet Security Network Configurator
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
