USGP2010MP
USGP2010MP SG-P2010-M-P PANASONIC Door safety switch, Cat.4, RFID, compact type, master ud. (std), exclusive..
$0.00USD
4002 in stock
Key Specifications
Item:Specifications
Cable:6–core cabtyre cable, 5 m16.404 ftlong
Remark:Where measurement conditions have not been specified precisely, the conditions used were ambient temperature +23 ℃+73 ℉.■Transponder specificationsOperating frequency: 125 kHzMax. transmitter output: 3.33 μW
Weight:Switch body (standard): 180 g approx., Actuator: 10 g approx.
Supplier Information
PANASONIC
Products: 4316
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Item | Specifications |
| Cable | 6–core cabtyre cable, 5 m16.404 ftlong |
| Remark | Where measurement conditions have not been specified precisely, the conditions used were ambient temperature +23 ℃+73 ℉.■Transponder specificationsOperating frequency: 125 kHzMax. transmitter output: 3.33 μW |
| Weight | Switch body (standard): 180 g approx., Actuator: 10 g approx. |
| Details | Compact type(High code / Standard) |
| Product | Non-Contact Safety Door Switch |
| Material | Switch body: PBT, PC, SUS (stainless steel), EPDMActuator: PBT |
| Part Number | SG-P2010-M-P |
| Gross weight | 260 g approx. |
| Product name | Non-Contact Safety Door Switch SG-P |
| Power voltage | 24V DC+10-20％ Ripple P-P 10 % or less |
| Response time | • For single unit: ON→OFF 100 ms or less, OFF→ON 100 ms or less• For multiple units: Time for single unit + 5 ms x (number of connected units - 1) |
| Product Number | SG-P2010-M-P |
| Pollution degree | 3 |
| Current consumption | 30 mA or less |
| Check input and output | Dedicated communication line between the switch body (standard) and the switch body (sub) (Note)* It is not for external input and output. (voltage range 0 V to 5 V DC)(Note) : When using the device as a single unit, connect the check input with the check output. |
| Connected cable length | • When using only one unit: Maximum cable length of 20 m 65.617 ft between switch body and power supply unit• When connecting multiple units in series: Maximum total cable length of 100 m328.084 ft, maximum cable length of 20 m65.617 ftbetween two adjacent units |
| Applicable standards:Japan | JIS B 9705-1, JIS C 0508-1 to 3 (SIL3), JIS B 9961, JIS C 8201-5-2, JIS B 9710 |
| Applicable standards:Europe | EN ISO 13849-1 : 2015 (Category 4, PLe), EN ISO 14119, EN 60947-5-3, EN 300 330, EN IEC 63000, EN 301 489-1 |
| Control outputs (OSSD 1, OSSD 2) | PNP open-collector transistor 2 outputs• Maximum source current: 100 mA• Applied voltage: Same as the power supply voltage (PNP output: between control output and +V)• Residual voltage: 2 V or less (source current and sink current: 100 mA) (excluding voltage drop due to cable)• Leakage current: 0.2 mA or less (including power OFF state)• Maximum load capacity: 0.47 μF• Load wiring resistance: 3 Ω or less |
| Operating distance : Front / Side | Sao (OFF→ON): 5 mm0.197 in, Sar (ON → OFF): 15 mm0.591 in |
| Applicable standards:North America | CAN/CSA C22.2 No.14, UL508 |
| Number of units connected in series | 30 units or less (standard 1 unit, sub 29 units) |
| Control output(OSSD):Protection circuit | Incorporated |
| Applicable regulations and certifications | CE Marking (Machinery Directive, RE Directive, RoHS Directive), UKCA Marking (Supply of Machinery (Safety) Regulations, RE Regulations, RoHS Regulations), TÜV SÜD certification, TÜV SÜD certification (U.S.A., Canada), the U.S.'s radio regulations (FCC) (Note), Canada's radio regulations (ICES-003, RSS-310) (Note), Singapore's radio regulations (IMDA certification) (Note), Thailand's radio regulations (NBTC certification) (Note), Philippines' radio regulations (NTC certification) (Note), Korea's radio regulations (KC certification) (Note), India's radio regulations (WPC certification) (Note), Indonesia's radio regulations (SDPPI certification) (Note), Malaysia's radio regulations (SIRIM certification) (Note)(Note) : This product uses a weak radio signal for its detection operation. Please confirm compliance with applicable laws in the country of use. |
| Environmental resistance:Ambient humidity | 30 to 85 % RH, storage: 30 to 95 % RH |
| Environmental resistance:Shock resistance | 300 m/s2(approx. 30 G), 3 times each in X, Y, and Z direction |
| Applicable standards:International standard | ISO 13849-1 : 2015 (Category 4, PLe), IEC 61508-1 to 3 (SIL3), IEC 62061 (SIL3), IEC 60947-5-3, ISO 14119 |
| Environmental resistance:Ambient temperature | -10 to +55 ℃+14 to +131 ℉(No dew condensation or icing allowed), Storage: -25 to +65 ℃-13 to +149 ℉ |
| Environmental resistance:Degree of protection | IP65（IEC） |
| Environmental resistance:Vibration resistance | 10 to 55Hz, 1 mm double amplitude, 2 hours each in X, Y, and Z directions |
| Environmental resistance:Insulation resistance | 20 MΩ or more, with 500 V DC megger between all supply terminals connected together and enclosure |
| Control outputs (OSSD 1, OSSD 2):Operation mode | • When the actuator is detected (safe state): ON• When the actuator is not detected (unsafe state or lockout state): OFF• When the switch body (sub) does not detect actuator (series connection): OFF |
| Environmental resistance:Voltage withstandability | 1,000 V AC for one minute between all supply terminals connected together and enclosure |
Product Description
SG-P2010-M-P_Non-Contact Safety Door Switch_Non-Contact Safety Door Switch SG-P_Compact type(High code / Standard)
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
