UFT40V
UFT40V FT-40V PANASONIC Vacuum resistant optical fiber, barrier, M4, temperature range -30 to 300°C, detecti..
$0.00USD
3661 in stock
Key Specifications
Item:Specifications
Details:Vacuum-resistant Fiber
Product:Thru-beam type Fiber
Free-cut:Not available
Supplier Information
PANASONIC
Products: 4316
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Item | Specifications |
| Details | Vacuum-resistant Fiber |
| Product | Thru-beam type Fiber |
| Free-cut | Not available |
| Fiber type | Vacuum-resistant |
| Application | Vacuum-resistant |
| Part Number | FT-40V |
| Semi-custom | Fiber length change |
| With sleeve | No |
| Product name | One-Touch Connection System Vacuum-resistant Fibers |
| Sensing mode | Thru-beam type |
| Mounting lens | Available |
| Beam direction | Top-view |
| Product Number | FT-40V |
| Applicable lens | FV-LE1, FV-SV1, FV-SV2 |
| Fiber head dia. | M4 |
| Fiber head length | 30 mm |
| Fiber cable length | 1m |
| Sensing range（STD） | 270 mm 10.630 in (FX-500 series) |
| Sensing range（FAST） | 160 mm 6.299 in (FX-500 series) |
| Sensing range（H-SP） | 55 mm 2.165 in (FX-500 series) |
| Sensing range（HYPR） | 1,000 mm 39.370 in (FX-500 series) |
| Sensing range（LONG） | 470 mm 18.504 in (FX-500 series) |
| Sensing range（U-LG） | 590 mm 23.228 in (FX-500 series) |
| Allowable bending radius | R25mm |
| Mounting protective tube | Not available |
| Sensing range（範囲） | 07##701-1000mm |
| Beam axis dia./ Spot diameter | dia. 1.3 mm |
| Fiber type（レンジ指定） | Particular use |
| Fiber head dia.（レンジ指定） | 02##M4 |
| Allowable bending radius（レンジ指定） | 08##R25mm |
| Environmental resistance : Ambient temperature MAX | 300 degrees |
| Environmental resistance : Ambient temperature MIN | -30 degrees |
| Environmental resistance : Ambient temperature MAX（レンジ指定） | 06##201-300 degrees |
| Environmental resistance : Ambient temperature MIN（レンジ指定） | 04##-30 degrees |
Product Description
FT-40V_Thru-beam type Fiber_One-Touch Connection System Vacuum-resistant Fibers_Vacuum-resistant Fiber
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
