In Stock Hot Product
TCS190X100BK
TCS190X100BK 2811330 CEMBRE TCS190X100BK TERMOCOIL
$0.00USD
3824 in stock
Key Specifications
Flammability: ():UL 224
Heat resistance: ():UL 224 250°C×4hr
Corrosive action: ():UL 224 158°C×168hr
Copper compatibility: ():UL 224 158°C×168hr
Supplier Information
CEMBRE
Products: 12084
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Flammability: () | UL 224 |
| Heat resistance: () | UL 224 250°C×4hr |
| Corrosive action: () | UL 224 158°C×168hr |
| Copper compatibility: () | UL 224 158°C×168hr |
| Insulation resistance: () | 600V UL 224 |
| Technical specifications: () | Test Method |
| Volume resistance (Ω.cm) () | IEC 93 |
| Elongation at failure (%): () | ASRM D2671 |
| Traction resistance (MPa): () | ASRM D2671 |
| Low temperature flexibility () | UL 224 -30°C×4hr |
| Dielectric strength (kv/mm): () | IEC 243 |
| Elongation at failure after heat aging (%): () | UL 224 158°C×168hr |
| Traction resistance after heat aging (MPa): () | UL 224 158°C×168hr |
| Halogen Free (Technical characteristicsOther characteristics) | yes |
| Material (Body) (Technical characteristicsOther characteristics) | Cross-linked polyolefin |
| Max operating temperature range (Technical characteristicsOther characteristics) | 125 °C |
| Min operating temperature range (Technical characteristicsOther characteristics) | -55 °C |
| Min shrinkaage ratio temperature (Technical characteristicsOther characteristics) | 70 °C |
Product Description
HEAT SHRINK BLACK Ø 19.0 MM TO Ø 9.0 MM
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
flame-retardant Polyolefin shrinkage ratio 2÷1
