In Stock Hot Product
ST-17P1N8ACK05S
ST-17P1N8ACK05S 1617874 PHOENIX CONTACT Panel feed-through, SPEEDCON locking, M17, Number of positions: 17, ..
$0.00USD
3235 in stock
Key Specifications
Note:Order information Order crimp contacts Ø 0.6 mm separately
Coding:N
Mounting type:4x Ø3.2
Conductor entry:11 mm ... 12.7 mm
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Note | Order information Order crimp contacts Ø 0.6 mm separately |
| Coding | N |
| Mounting type | 4x Ø3.2 |
| Conductor entry | 11 mm ... 12.7 mm |
| Type of locking | SPEEDCON locking |
| Type of contacts | Male connector |
| Ambient temperature | -40 °C ... 125 °C |
| Number of positions | 17 |
| Degree of protection | IP67 |
| Installation height max. | 3000 m |
| Contact connection method | Crimp connection |
| Contact diameter of power contacts | 0.6 mm |
| Pollution degree of power contacts | 3 |
| Rated surge voltage of power contacts | 1.5 kV |
| Overvoltage category of power contacts | II |
| Nominal current per power contact at 25°C | 3.6 A |
| Nominal / operating voltage of power contacts | 60 V |
| Direction of rotation of contact chamber numbering | Standard |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
