SPV-300-24
SPV-300-24 MEANWELL AC-DC Enclosed power supply, Output 24VDC / 12.5A, forced air cooling, Programmable outp..
$70.55USD
173 in stock
Key Specifications
Fan:Yes
Name:SPV-300-24
Format:Box
Series:SPV-300
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Fan | Yes |
| Name | SPV-300-24 |
| Format | Box |
| Series | SPV-300 |
| Approvals | CE, UL |
| Power (W) | 300,00 |
| Subformato | Grid |
| Width (mm) | 115.00 |
| Height (mm) | 50.00 |
| AC input Max | 264,00 |
| AC input Min | 88,00 |
| Applications | Industrial, Telecommunications |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Isolation (V) | 3.000,00 |
| Output voltage | 24,00 |
| Peak Power (W) | Three hundred |
| Input connector | Screw-Type |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 215.00 |
| Long Description | Switch mode Power supply.Format in case of grid.Range of universal Input88-264vac47-63Hz.Output voltage24vdc. Adjustable by potentiometer (20-26,4 Vcc).Output voltage programmable between 20% and 110% by external signal of 1 to 5.5 Vdc.Output intensity12.5 To. Range of output current 0-12,5 To according to demand load.Factor Corrector, Power>0,95.Power:300W.Efficiency typical:85%.Remote on / off.Working temperature: from-20ºCup+65ºCof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:215 x 115 x 50.3 years of warranty.Manufacturer: MEAN WELLThe series SPV are sources of alimentacíon with programmable output. They are designed to test applications during manufacture in order to apply different stresses during the production or regulate the power of engines of continuous or similar applications where we need to vary the supply voltage.The output voltage can be set between 20% and 120% of the nominal output voltage by an external signal of 1-5,5 Vdc. |
| Output connector | Screw-Type |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 3,00 |
| Country of Origin | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Switch mode Power supply.
