SPT 2,5/ 6-V-5,0 RD
SPT 2,5/ 6-V-5,0 RD 1705926 PHOENIX CONTACT Terminal block for printed circuit board, rated current: 24 A, r..
$0.00USD
4488 in stock
Key Specifications
UNSPSC 11 (ETIM):39121432
ETIM 3.0 (eCl@ss):EC001121
ETIM 4.0 (eCl@ss):EC002643
ETIM 5.0 (eCl@ss):EC002643
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| UNSPSC 11 (ETIM) | 39121432 |
| ETIM 3.0 (eCl@ss) | EC001121 |
| ETIM 4.0 (eCl@ss) | EC002643 |
| ETIM 5.0 (eCl@ss) | EC002643 |
| ETIM 6.0 (eCl@ss) | EC002643 |
| UNSPSC 13.2 (ETIM) | 39121432 |
| UNSPSC 6.01 (ETIM) | 30211801 |
| UNSPSC 12.01 (ETIM) | 39121432 |
| UNSPSC 7.0901 (ETIM) | 39121432 |
| GTIN (Your advantages) | 4046356808217 |
| Note (Connection capacity) | WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201 |
| Orderkey (Your advantages) | 1705926 |
| Voltage (Electrical tests) | 250 V |
| (Standards and Regulations) | No hazardous substances above threshold values |
| Packing unit (Your advantages) | 1 |
| Pitch (Material data - housing) | 5 mm |
| Rated current (Ambient conditions) | 24 A |
| Rated current (Key Commercial Data) | 24 A |
| Dimension a (Material data - housing) | 25 mm |
| Pin spacing (Material data - housing) | 8.2 mm |
| Width [ w ] (Material data - housing) | 31.4 mm |
| China RoHS (Standards and Regulations) | Environmentally friendly use period: unlimited = EFUP-e |
| Contact material (Connection capacity) | Cu alloy |
| Custom tariff number (Your advantages) | 85369010 |
| Height [ h ] (Material data - housing) | 16.9 mm |
| Length [ l ] (Material data - housing) | 13.5 mm |
| Housing color (Material data - contact) | red (3001) |
| Pin dimensions (Material data - housing) | 0.8 x 0.8 mm |
| Pin spacing (Dimensions for the product) | 8.2 mm |
| Solder pin [P] (Material data - housing) | 2.5 mm |
| Stripping length (Electrical parameters) | 10 mm |
| Hole diameter (Dimensions for the product) | 1.1 mm |
| Insulating material group (Electrical tests) | I |
| Dimensional drawing (Material data - housing) | |
| Insulating material (Material data - contact) | PA |
| Rated surge voltage (II/2) (Electrical tests) | 4 kV |
| Surface characteristics (Connection capacity) | hot-dip tin-plated |
| Type of packaging (Dimensions for PCB design) | packed in cardboard |
| eCl@ss 4.0 (Environmental Product Compliance) | 27141111 |
| eCl@ss 4.1 (Environmental Product Compliance) | 27141109 |
| eCl@ss 5.0 (Environmental Product Compliance) | 27141190 |
| eCl@ss 5.1 (Environmental Product Compliance) | 27141190 |
| eCl@ss 6.0 (Environmental Product Compliance) | 27261101 |
| eCl@ss 7.0 (Environmental Product Compliance) | 27440401 |
| eCl@ss 8.0 (Environmental Product Compliance) | 27440401 |
| eCl@ss 9.0 (Environmental Product Compliance) | 27440401 |
| Pieces per package (Dimensions for PCB design) | 50 |
| Rated surge voltage (III/2) (Electrical tests) | 4 kV |
| Rated surge voltage (III/3) (Electrical tests) | 4 kV |
| Rated surge voltage (III/2) (Ambient conditions) | 4 kV |
| Rated surge voltage (III/2) (Key Commercial Data) | 4 kV |
| Rated insulation voltage (II/2) (Electrical tests) | 630 V |
| Rated insulation voltage (III/2) (Electrical tests) | 400 V |
| Rated insulation voltage (III/3) (Electrical tests) | 250 V |
| CTI according to IEC 60112 (Material data - contact) | 600 |
| Conductor cross section solid (Electrical parameters) | 0.2 mm² ... 4 mm² |
| Height (without solder pin) (Material data - housing) | 14.4 mm |
| Rated insulation voltage (III/2) (Ambient conditions) | 400 V |
| Ambient temperature (assembly) (Packaging information) | -5 °C ... 100 °C |
| Denomination packing units (Dimensions for PCB design) | Pcs. |
| Rated insulation voltage (III/2) (Key Commercial Data) | 400 V |
| Ambient temperature (operation) (Packaging information) | -40 °C |
| Conductor cross section flexible (Electrical parameters) | 0.2 mm² ... 2.5 mm² |
| Minimum creepage distance value (II/2) (Electrical tests) | 3.2 mm |
| Minimum creepage distance value (III/2) (Electrical tests) | 2 mm |
| Minimum creepage distance value (III/3) (Electrical tests) | 3.2 mm |
| Conductor cross section AWG / kcmil (Electrical parameters) | 24 ... 12 |
| Ambient temperature (storage/transport) (Packaging information) | -40 °C ... 70 °C |
| Flammability rating according to UL 94 (Material data - contact) | V0 |
| Comparative tracking index (IEC 60112:2003-01) (Electrical tests) | CTI 600 |
| Minimum clearance - inhomogeneous field (II/2) (Electrical tests) | 3 mm |
| Minimum clearance - inhomogeneous field (III/2) (Electrical tests) | 3 mm |
| Minimum clearance - inhomogeneous field (III/3) (Electrical tests) | 3 mm |
| Connection in acc. with standard (Air clearances and creepage distances) | EN-VDE |
| Glow wire flammability index GWFI according to EN 60695-2-12 (Material data - contact) | 850 |
| Glow wire ignition temperature GWIT according to EN 60695-2-13 (Material data - contact) | 775 |
| Temperature for the ball pressure test according to EN 60695-10-2 (Material data - contact) | 125 °C |
| Conductor cross section flexible, with ferrule without plastic sleeve (Electrical parameters) | 0.25 mm² ... 2.5 mm² (Stripping length 8 mm) |
Product Description
Terminal block for printed circuit board, nominal current: 24 A, nominal voltage (III/2): 400 V, nominal section: 2.5 mm², number of potentials: 6, number of rows: 1, number of poles per row: 6, famil
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
PCB terminal block, nominal current: 24 A, nom. voltage: 400 V, pitch: 5 mm, number of positions: 6, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 90 °, color: red
