SP-75-12
SP-75-12 MEANWELL AC-DC Enclosed power supply, Output 12VDC / 6.3A, PFC, free air convection
$0.00USD
4553 in stock
Key Specifications
Name:SP-75-12
State:Do not Use for New Designs
Format:Box
Series:SP-75
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | SP-75-12 |
| State | Do not Use for New Designs |
| Format | Box |
| Series | SP-75 |
| Approvals | CE, UL |
| Power (W) | 75,60 |
| Subformato | Grid |
| Width (mm) | 97.00 |
| Height (mm) | 33.00 |
| AC input Max | 264,00 |
| AC input Min | 85,00 |
| Applications | Industrial, Telecommunications |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Isolation (V) | 3.000,00 |
| Output voltage | 12,00 |
| Peak Power (W) | 75.6 |
| Input connector | Screw-Type |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 179.00 |
| Long Description | Switch mode Power supply.Format in Box.Range of universal Input85-264vac47-63Hz.Output voltage12vdc. Adjustable by potentiometer (11,4-13,2 Vdc).Output intensity6.3 A. Range of output current, 0 to 6.3 A as it requires you to load.Factor Corrector, Power>To 0.93.Power:75,6 W.Efficiency typical:81%.Working temperature: from-10ºCup+60 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) :179 x 97 x 33mm.3 years of warranty.Manufacturer: MEAN WELL.The SP series are switching power supplies with correction factor power active, which include the possibility of performing a power on/off remote. |
| Output connector | Screw-Type |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 3,00 |
| Country of Origin | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Switch mode Power supply.
