In Stock Hot Product
SP-200-15
SP-200-15 MEANWELL AC-DC Single output enclosed power supply with PFC, Input range 85-264VAC, Output 15VDC /..
$0.00USD
4878 in stock
Key Specifications
Fan:Yes
Name:SP-200-15
State:Do not Use for New Designs
Format:Box
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Fan | Yes |
| Name | SP-200-15 |
| State | Do not Use for New Designs |
| Format | Box |
| Series | SP-200 |
| Approvals | CCC, CE, UL |
| Power (W) | 201,10 |
| Subformato | Grid |
| Width (mm) | 99.00 |
| Height (mm) | 50.00 |
| AC input Max | 264,00 |
| AC input Min | 85,00 |
| Applications | Industrial, Telecommunications |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Isolation (V) | 3.000,00 |
| Output voltage | 15,00 |
| Peak Power (W) | Two hundred one |
| Input connector | Screw-Type |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 199.00 |
| Long Description | Switch mode Power supply.Format in Box.Range of universal Input85-264vac47-63Hz.Output voltage15vdc. Adjustable by potentiometer (14,3-16,5 Vdc).Output intensity13.4 To. Range of output current 0-13,4 according To the demand load.Factor Corrector, Power>To 0.93.Power:201W.Efficiency typical:84%.Working temperature: from-10ºCup+60 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) :199 x 99 x 50mm.3 years of warranty.Manufacturer: MEAN WELLThe series SP-200 are switching power supplies with correction factor power active, having the ability to make on/off remote and include a fan for cooling controllable in on/off and speed depending on the models. |
| Output connector | Screw-Type |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 3,00 |
| Country of Origin | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Switch mode Power supply.
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
