In Stock Hot Product
SKV 7/B
SKV 7/B 10066191 WISKA Black cable glands RAL 9005, PA IP68, range from 3.0 to 6.0mm, thread PG 07
$0.00USD
3614 in stock
Key Specifications
Type (Features):SKV 7
Thread type (Features):PG
Key width SW (Features):15 mm
Packing unit (Features):50
Supplier Information
WISKA
Products: 2869
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Type (Features) | SKV 7 |
| Thread type (Features) | PG |
| Key width SW (Features) | 15 mm |
| Packing unit (Features) | 50 |
| Product Color (Features) | RAL 9005 |
| Glow wire test (Features) | 750 °C |
| Temp. range max (Features) | 100 °C |
| Temp. range min (Features) | -40 °C |
| Total length TL (Features) | 28 mm - 32 mm |
| Protection class (Features) | IP68 (5 bar 30 min) |
| Order no. RAL 9005 (Features) | 10066191 |
| Collar diameter (E) (Features) | 16 mm |
| ETIM-Classification (Features) | EC000441 |
| Material cable gland (Features) | Polyamide |
| Ø cable diameter max (Features) | 6 mm |
| Ø cable diameter min (Features) | 3 mm |
| Ø Connection thread D (Features) | 7 |
| Material sealing gasket (Features) | EPDM |
| Type of cable anchorage (Features) | A |
| Length screw-in thread L (Features) | 9 mm |
Product Description
Cable gland, polyamide, Pg 7, RAL 9005
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
