SKV 42/B
SKV 42/B 10066199 WISKA Black cable glands RAL 9005, PA IP68, range from 28.0 to 38.0mm, thread PG 42
$0.00USD
4012 in stock
Key Specifications
Type (Features):SKV 42
Thread type (Features):PG
Key width SW (Features):60 mm
Packing unit (Features):5
Supplier Information
WISKA
Products: 2869
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Type (Features) | SKV 42 |
| Thread type (Features) | PG |
| Key width SW (Features) | 60 mm |
| Packing unit (Features) | 5 |
| Product Color (Features) | RAL 9005 |
| Glow wire test (Features) | 750 °C |
| Temp. range max (Features) | 100 °C |
| Temp. range min (Features) | -40 °C |
| Total length TL (Features) | 58 mm - 67 mm |
| Protection class (Features) | IP68 (5 bar 30 min) |
| Order no. RAL 9005 (Features) | 10066199 |
| Collar diameter (E) (Features) | 67 mm |
| ETIM-Classification (Features) | EC000441 |
| Material cable gland (Features) | Polyamide |
| Ø cable diameter max (Features) | 38 mm |
| Ø cable diameter min (Features) | 28 mm |
| Ø Connection thread D (Features) | 42 |
| Material sealing gasket (Features) | EPDM |
| Type of cable anchorage (Features) | A |
| Length screw-in thread L (Features) | 14 mm |
Product Description
Cable gland, polyamide, Pg 42, RAL 9005
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
