In Stock Hot Product
SKV 29/G
SKV 29/GL 10066007 WISKA Light grey cable glands RAL 7035, PA IP68, range from 16.0 to 25.0mm, thread PG 29
$0.00USD
4599 in stock
Key Specifications
Type (Features):SKV 29
Thread type (Features):PG
Key width SW (Features):42 mm
Packing unit (Features):20
Supplier Information
WISKA
Products: 2869
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Type (Features) | SKV 29 |
| Thread type (Features) | PG |
| Key width SW (Features) | 42 mm |
| Packing unit (Features) | 20 |
| Product Color (Features) | RAL 7001 |
| Glow wire test (Features) | 750 °C |
| Temp. range max (Features) | 100 °C |
| Temp. range min (Features) | -40 °C |
| Total length TL (Features) | 47 mm - 56 mm |
| Protection class (Features) | IP68 (5 bar 30 min) |
| Order no. RAL 7001 (Features) | 10066007 |
| Collar diameter (E) (Features) | 46 mm |
| ETIM-Classification (Features) | EC000441 |
| Material cable gland (Features) | Polyamide |
| Ø cable diameter max (Features) | 25 mm |
| Ø cable diameter min (Features) | 16 mm |
| Ø Connection thread D (Features) | 29 |
| Material sealing gasket (Features) | EPDM |
| Type of cable anchorage (Features) | A |
| Length screw-in thread L (Features) | 12 mm |
Product Description
Cable gland, polyamide, Pg 29RAL 7001
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
