SH4/E-1EIC
SH4/E-1EIC MICRO DETECTORS Safety sensor Emitter M18 11m metallic axial plug M12 I/O IEC61131-2 f 123 kHz
$0.00USD
3566 in stock
Key Specifications
PL:e
SIL:3
PFHd:8,1E--10
Type:4
Supplier Information
MICRO DETECTORS
Products: 33669
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| PL | e |
| SIL | 3 |
| PFHd | 8,1E--10 |
| Type | 4 |
| MTTFd | 20 |
| Notes | not working with SBCR03 control unit.To be used with external safety control unit with automatic optics test function |
| SILCL | 3 |
| Emission | Red |
| humidity | 15% … 95% |
| Approvals | CE, TÜV |
| Dimensions | M18 |
| Connections | M12 plug |
| Test levels | <5V emission inactive>15V emission active |
| LED indicators | Yellow (power) |
| Housing Material | PBT |
| Operating Voltage | 10 … 30 Vdc |
| Function Principle | Through-beam (emitter) |
| Max ripple content | ≤ 5 Vpp |
| Storage temperature | -40°C … +75°C |
| Thermal drift of Sr | ≤ 10% |
| Active Head Material | Glass |
| Degree of protection | IP67 |
| Supplied Accessories | 2 x nuts |
| Operating temperature | -20°C … +55°C |
| Shocks and vibrations | 10g - 16ms (according to IEC600068-2-29)10Hz…55Hz - 1 oct/min - 0,35mm (according to 60068-2-6) |
| No-Load supply current | ≤ 25mA |
| Effective Aperture Angle | Typical ±1,8° |
| Nominal sensing distance | 5m (ExG=2) |
Product Description
SH4/E-1EIC Safety sensor Emitt. M18 11m metal. axial conn.M12 I/O IEC61131-2 f=123 kHz
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
