SD-WMS 16 (NU) YE
SD-WMS 16 (NU) YE 0826352 PHOENIX CONTACT Conductor marking collar
$0.00USD
4697 in stock
Key Specifications
Type:Profile
Color:yellow
Width:6.2 mm
Height:16.5 mm
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Type | Profile |
| Color | yellow |
| Width | 6.2 mm |
| Height | 16.5 mm |
| Length | 11 mm |
| Result | Test passed |
| General | Please specify the required marking with order: Minimum order per imprint: 1 packing unit |
| Material | Polyvinyl chloride |
| Printing | Numbers |
| Components | Free from silicone and cadmium |
| Product type | Labeled conductor marker |
| Mounting type | thread on |
| Specification | ISO 4892-2:2013-03 (following) |
| Test duration | 96 h |
| Wipe resistance | DIN EN 61010-1 (VDE 0411-1) |
| Outside diameter | 8 mm ... 16 mm |
| Printing direction | horizontal |
| Ambient temperature (operation) | -30 °C ... 60 °C |
| Flammability rating according to UL 94 | V0 |
Product Description
Conductor marking collar, yellow, horizontal: Numbers, mounting type: thread on, cable diameter range: 8 ... 16 mm, lettering field size: 6.2 x 4 mm
