SBTN01N-15
SBTN01N-15 MEANWELL DC-DC Converter for PCB mount, Input 21.6-26.4VDC, Output 15VDC / 0.007-0.07A, SMD packa..
$0.00USD
4231 in stock
Key Specifications
Name (Details):SBTN01N-15
State (Details):New
Format (Details):For Printed Circuit
Series (Details):SBTN01
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name (Details) | SBTN01N-15 |
| State (Details) | New |
| Format (Details) | For Printed Circuit |
| Series (Details) | SBTN01 |
| Approvals (Details) | EC, EAC |
| Power (W) (Details) | 1,00 |
| Subformato (Details) | SMD |
| Width (mm) (Details) | 10.9 |
| Height (mm) (Details) | 7.1 |
| Input range (Details) | +/-10% |
| Applications (Details) | Automation of Buildings, Industrial, Instrumentation, Telecommunications |
| DC input Max (Details) | 26,40 |
| DC input Min (Details) | 21,60 |
| Manufacturer (Details) | MEAN WELL |
| Product type (Details) | Dc/DC converters |
| Isolation (V) (Details) | 1.500,00 |
| Output voltage (Details) | 15,00 |
| Peak Power (W) (Details) | One |
| Input connector (Details) | Pin |
| Long/Background (Details) | 12.9 |
| Long Description (Details) | DC/DC converter to the printed circuit board in format SMD, with isolation of 1500Vcc. Not regulated.FormatSMDfor printed circuit boards.Input range21,6-26,4Vcc.Output voltage15vdc.Output intensity6,7-67th.Power:1W.Isolation input-output 1500Vcc.Efficiency typical:78%.Low noise and ripple 75mVp-p.Minimum load of 10%. The no-load operation will not damage the converter but will not meet all specifications.Protection against short circuit and over load (0.5 seconds).Working temperature: from-40up+90 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:The 12.9 x 10.9 in x 7.1.3 years of warranty.Manufacturer: MEAN WELL.The new series SBTN01 are converters 1W isolated and not regulated. Complies with the EN55032 class B without additional components and have a wide range of temperature operation, and isolation between input and output de1500Vcc. Are protected against overloads and short-circuits.CE certificates and EAC. |
| Output connector (Details) | Pin |
| Warranty (Years) (Details) | 3,00 |
| Country of Origin (Details) | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
DC/DC converter to the printed circuit board in format SMD, with isolation of 1500Vcc. Not regulated.
