SB110
SB110 MICRO DETECTORS M12 plug, 8 poles, without cable
$0.00USD
4640 in stock
Key Specifications
Notes:With 100x100 mm white matt paper
Weight:75g
Emission:Infrared (880nm)
Approvals:CE
Supplier Information
MICRO DETECTORS
Products: 33669
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Notes | With 100x100 mm white matt paper |
| Weight | 75g |
| Emission | Infrared (880nm) |
| Approvals | CE |
| Dimensions | 21,4mmx89,8mm |
| Connections | Right angle cable 2m PVC |
| Output type | NPN |
| Load current | ≤100mA |
| LED indicators | Yellow (output energized), green (supply), red (activated output) |
| Optic position | Axial |
| Leakage current | ≤10µA |
| Output Function | LO/DO selectable |
| Repeat Accuracy | 5% |
| Housing Material | PBT |
| EMC compatibility | EN 60947-5-2 |
| Operating Voltage | 10-30Vdc |
| Tightening torque | 1Nm |
| Function Principle | Diffuse reflection |
| Max ripple content | ≤ 10% |
| Output voltage drop | ≤2V IL=100mA |
| Switching frequency | 1kHz |
| Thermal drift of Sr | 10% Sr |
| Active Head Material | PMMA |
| Degree of protection | IP67 |
| Supplied Accessories | Metallic nut (2x) |
| Operating temperature | - 25°C…+ 70° C (without freeze) |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 |
| No-Load supply current | ≤30mA |
| Sensitivity adjustment | Trimmer |
| Nominal sensing distance | 150mm |
| Short-circuit protection | Yes |
| Reverse Polarity Protection | Yes |
| Interference to external light | 3.000lux (incandescent lamp), 10.000lux (sunlight) |
| Time delay before availability | 200ms |
