SACC-DSI-MINMS-5CON-UNF PCB
SACC-DSI-MINMS-5CON-UNF PCB 1457487 PHOENIX CONTACT Sensor/actuator flush-type plug, 5-pos., 7/8", PCB mount..
$0.00USD
3238 in stock
Key Specifications
GTIN:4046356616997
Note:Made to Order (non-returnable)
Orderkey:1457487
Catalog page:Page 267 (C-2-2013)
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4046356616997 |
| Note | Made to Order (non-returnable) |
| Orderkey | 1457487 |
| Catalog page | Page 267 (C-2-2013) |
| Packing unit | 1 pc |
| Country of origin | DE (Germany) |
| Custom tariff number | 85366990 |
| Contact material (General) | CuZn |
| Material, knurls (General) | Zinc die-cast, nickel-plated |
| Sealing material (General) | Viton |
| Coding (Ambient conditions) | A - standard |
| (Standards and Regulations) | For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
| Contact carrier material (General) | PUR |
| Contact surface material (General) | Au |
| Mounting type (Ambient conditions) | PCB mounting 7/8" |
| Rated voltage (Ambient conditions) | 250 V |
| Status display (Ambient conditions) | No |
| Weight per Piece (excluding packing) | 46.700 g |
| China RoHS (Standards and Regulations) | Environmentally Friendly Use Period = 25; |
| Connection method (Ambient conditions) | Solder pins |
| REACh SVHC (Standards and Regulations) | Lead 7439-92-1 |
| Degree of pollution (Ambient conditions) | 3 |
| Number of positions (Ambient conditions) | 5 |
| Overvoltage category (Ambient conditions) | II |
| Degree of protection (Key Commercial Data) | IP67 |
| Insulation resistance (Ambient conditions) | ≥ 100 MΩ |
| Connection in acc. with standard (Material) | CUL |
| Rated current at 40°C (Ambient conditions) | 9 A |
| Flammability rating according to UL 94 (General) | HB |
| Flammability rating according to UL 94 (Material) | HB |
| Ambient temperature (operation) (Key Commercial Data) | -40 °C ... 85 °C (Plug) |
