RXP/00-3B
RXP/00-3B MICRO DETECTORS Photoelectric sensor polarised AC. Relay with fixing slide plug M12
$0.00USD
3976 in stock
Key Specifications
Weight:90g
Emission:Red (660nm)
Approvals:CE
Dimensions:26x86,6x61
Supplier Information
MICRO DETECTORS
Products: 33669
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Weight | 90g |
| Emission | Red (660nm) |
| Approvals | CE |
| Dimensions | 26x86,6x61 |
| Connections | M12 plug |
| Output type | Relay |
| Load current | 3A-250Vac/3A-30Vdc (750VA/90W) |
| LED indicators | Rear red (output state), superior red ( alignment), green ( stable signal) |
| Optic position | Axial |
| Repeat Accuracy | 5% |
| EMC compatibility | EN 60947-5-2 |
| Operating Voltage | 20-253Vac/ 20-60Hz |
| Function Principle | Polarized |
| Switching frequency | 25Hz |
| Thermal drift of Sr | 10% Sr |
| Degree of protection | IP65 |
| Supplied Accessories | ST81 mounting bracket and screws |
| Operating temperature | - 25°C…+ 70°C ( without freeze) |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-28 |
| No-Load supply current | 25mARMS |
| Sensitivity adjustment | Single-turn potentiometer |
| Nominal sensing distance | 6m with standard reflector Ø80mm (RL110 supplied separately) |
| Reverse Polarity Protection | Yes |
| Interference to external light | ≥ 10000lux (incandescent lamp) |
| Time delay before availability | 100ms |
| Impulsive Overvoltage Protection | Yes |
Product Description
RXP/00-3B Photoelectric sensor Polarised AC. Relay with fixing slide conn. M12
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
