In Stock Hot Product
REL-SR- 24DC/2X21
REL-SR- 24DC/2X21 2961574 PHOENIX CONTACT Safety relays
$0.00USD
3035 in stock
Key Specifications
GTIN:4017918996796
Note:Made to Order (non-returnable)
Orderkey:2961574
(General):IEC 60664-1
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4017918996796 |
| Note | Made to Order (non-returnable) |
| Orderkey | 2961574 |
| (General) | IEC 60664-1 |
| Catalog page | Page 279 (C-6-2017) |
| Packing unit | 10 pc |
| Country of origin | CZ (Czech Republic) |
| Custom tariff number | 85364190 |
| Insulation (General) | Safe isolation, reinforced insulation |
| Designation (General) | Air clearances and creepage distances between the power circuits |
| Minimum order quantity | 10 pc |
| Depth (Key Commercial Data) | 25.5 mm |
| Width (Key Commercial Data) | 12.6 mm |
| (Standards and Regulations) | No hazardous substances above threshold values |
| Height (Key Commercial Data) | 29 mm |
| Degree of pollution (General) | 2 |
| Rated surge voltage (General) | 6 kV |
| Overvoltage category (General) | III |
| Relay type (Ambient conditions) | Electromechanical relay with forcibly guided contacts in accordance with EN 50205 |
| Standards/regulations (General) | DIN EN 50178 |
| Rated insulation voltage (General) | 250 V AC |
| Weight per Piece (excluding packing) | 17.000 g |
| Net weight (SAP) (Ambient conditions) | 16.995 g |
| China RoHS (Standards and Regulations) | Environmentally friendly use period: unlimited = EFUP-e |
| Degree of protection (Ambient conditions) | IP20 |
| Ambient temperature (operation) (Dimensions) | -25 °C ... 70 °C |
| Mechanical service life (Ambient conditions) | approx. 107cycles |
| Ambient temperature (storage/transport) (Dimensions) | -25 °C ... 70 °C |
Product Description
Safety relay with forced conduction contacts according to EN 50205, contact version 2 switched contacts, connection suitable for mounting on printed circuit boards. The requirements for Type A accordi
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
