RDDW08G-05
RDDW08G-05 MEANWELL DC-DC Railway Dual Output Converter, Input 18-75VDC, Output ±5VDC / ±0.8A, 1.5KVDC I/O i..
$0.00USD
4572 in stock
Key Specifications
Name (Details):RDDW08G-05
State (Details):New
Format (Details):For Printed Circuit
Series (Details):RSDW08 & RDDW08
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name (Details) | RDDW08G-05 |
| State (Details) | New |
| Format (Details) | For Printed Circuit |
| Series (Details) | RSDW08 & RDDW08 |
| Output 1 (Details) | -5 |
| Output 2 (Details) | +5 |
| Approvals (Details) | EC, EAC, EN50155 |
| Power (W) (Details) | 8,00 |
| Subformato (Details) | DIP |
| Width (mm) (Details) | 20.3 |
| Height (mm) (Details) | 10.2 |
| Input range (Details) | 4:1 |
| Applications (Details) | Rail, Industrial, Instrumentation, Telecommunications |
| DC input Max (Details) | 75,00 |
| DC input Min (Details) | 18,00 |
| Manufacturer (Details) | MEAN WELL |
| Product type (Details) | Dc/DC converters |
| Isolation (V) (Details) | 1.500,00 |
| Peak Power (W) (Details) | Eight |
| Input connector (Details) | Pin |
| Long/Background (Details) | 31.8 |
| Long Description (Details) | DC/DC converter for rail printed circuit board in format DIP24. Input range 4:1. Isolation 1500Vcc.Format for soldering in printed circuit boardDIP24.Input range18-75Vcc.Outputs:-5vdc:Without the need of minimum load.Maximum output current -0.8 A.+5vdc:Without the need of minimum load.Maximum output current0.8 A.Power:8W.Efficiency typical:83%.Low noise and ripple 50mVp-p.Remote on / off.Working temperature: from-40up+85 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:31,8 x 20,3 x 10,2.3 years of warranty.Manufacturer: MEAN WELL.The new series RSDW08 & RDDW08 are converters of high reliability for railway applications in format DIP24 with input range of 4:1. Are certified to comply with the standard railway EN50155 .They have a wide range of temperature operation, and isolation between input and output of 1500Vcc. Are protected against overloads, short-circuits, over-voltage and output under-voltage input. Include a filter Pi internally. Requires external components to pass the EMC EN55032 (see recommended outline).CE certificate and EAC. |
| Output connector (Details) | Pin |
| Warranty (Years) (Details) | 3,00 |
| Country of Origin (Details) | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
DC/DC converter for rail printed circuit board in format DIP24. Input range 4:1. Isolation 1500Vcc.
