RC-2RP1N1282NN
RC-2RP1N1282NN 1613306 PHOENIX CONTACT Cable connector, termination connector, straight, shielded: yes, Scre..
$0.00USD
4026 in stock
Key Specifications
:74 V DC
Coding:N
Application:Signal
Thread type:M23
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| 74 V DC | |
| Coding | N |
| Application | Signal |
| Thread type | M23 |
| Product type | Circular connector (cable-side) |
| Rated voltage | 48 V AC |
| Type of locking | Screw locking mechanism |
| Housing material | Metal |
| Connection method | Solder connection |
| Connection profile | 11+PE |
| Degree of pollution | 3 |
| Number of positions | 12 |
| Pg screw connection | none |
| Rated surge voltage | 1.5 kV |
| Overvoltage category | III |
| Direction of rotation | Standard |
| Contact switching type | Pin |
| Rated currentPower contacts | 10 A |
| Contact diameterPower contacts | 1 mm |
| Contact diameterSignal contacts | 1 mm |
| Degree of protection (plugged in) | IP67 |
| Nominal current per signal contact | 8 A |
| Flammability rating according to UL 94 | V0 |
| Litz wire cross-sectionPower contactsmax. | 1 mm² |
| Litz wire cross-sectionPower contactsmin. | 0.08 mm² |
| Litz wire cross-sectionSignal contactsmax. | 1 mm² |
| Litz wire cross-sectionSignal contactsmin. | 0.08 mm² |
Product Description
Industrial connector, locking connector, straight, shielded: yes, Screw lock, M23, No. of poles: 11+PE, Contact type: Pin, Soldering connection
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
