RC-12SDN8A80E2
RC-12SDN8A80E2 1615396 PHOENIX CONTACT Cable connector
$0.00USD
4718 in stock
Key Specifications
GTIN:4046356498500
Orderkey:1615396
Packing unit:1
(Cable seal data):For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration”
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4046356498500 |
| Orderkey | 1615396 |
| Packing unit | 1 |
| (Cable seal data) | For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
| Custom tariff number | 85366990 |
| Note (Key Commercial Data) | Order information: Order crimp contacts Ø 1 mm separately |
| China RoHS (Cable seal data) | Environmentally Friendly Use Period = 50 |
| Coding (Key Commercial Data) | N |
| REACh SVHC (Cable seal data) | Lead 7439-92-1 |
| Cable diameter (Housing data) | 5.5 mm ... 6.5 mm |
| Sealing material (Housing data) | NBR |
| Application (Key Commercial Data) | Signal |
| Type of contacts (Key Commercial Data) | Socket |
| Thread type (Data of the insulating body) | M23 |
| Type of locking (Data of the insulating body) | Screw locking |
| Housing material (Data of the insulating body) | Metal |
| Contact connection method (Key Commercial Data) | Crimp connection |
| Contact diameter of power contacts (Key Commercial Data) | 1 mm |
| Nominal current per power contact at 25°C (Key Commercial Data) | 8 A |
| Degree of protection (when plugged in) (Data of the insulating body) | IP67 |
Product Description
M23, Plug connector. for cables, straight, shielded: no, Screw lock, No. of poles: 12, Direction of rotation: Opposite movement, type of contact: Female, Crimped connection, Cable diameter range: 5.5
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
