RC-06P1N122S00
RC-06P1N122S00 1593111 PHOENIX CONTACT Device connector for front wall, RC, straight, shielded: yes, Screw l..
$0.00USD
4023 in stock
Key Specifications
GTIN:4046356194341
Orderkey:1593111
(Drawings):
Packing unit:1
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4046356194341 |
| Orderkey | 1593111 |
| (Drawings) | |
| Packing unit | 1 |
| (Housing data) | For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
| UNSPSC 11 (ETIM) | 43172015 |
| Coding (Drawings) | N |
| ETIM 3.0 (eCl@ss) | EC001121 |
| ETIM 4.0 (eCl@ss) | EC001121 |
| ETIM 5.0 (eCl@ss) | EC002635 |
| ETIM 6.0 (eCl@ss) | EC001121 |
| ETIM 7.0 (eCl@ss) | EC001121 |
| UNSPSC 13.2 (ETIM) | 39121413 |
| UNSPSC 18.0 (ETIM) | 39121413 |
| UNSPSC 19.0 (ETIM) | 39121413 |
| UNSPSC 20.0 (ETIM) | 39121413 |
| UNSPSC 21.0 (ETIM) | 39121413 |
| UNSPSC 6.01 (ETIM) | 43172015 |
| UNSPSC 12.01 (ETIM) | 43201404 |
| Custom tariff number | 85366990 |
| UNSPSC 7.0901 (ETIM) | 43201404 |
| Application (Drawings) | Signal |
| China RoHS (Housing data) | Environmentally Friendly Use Period = 50 |
| REACh SVHC (Housing data) | Lead 7439-92-1 |
| Type of contacts (Drawings) | Pin |
| eCl@ss 4.0 (Classifications) | 272607xx |
| eCl@ss 4.1 (Classifications) | 27260701 |
| eCl@ss 5.0 (Classifications) | 27260701 |
| eCl@ss 5.1 (Classifications) | 27260701 |
| eCl@ss 6.0 (Classifications) | 27260708 |
| eCl@ss 7.0 (Classifications) | 27440312 |
| eCl@ss 8.0 (Classifications) | 27440103 |
| eCl@ss 9.0 (Classifications) | 27440102 |
| Degree of pollution (Drawings) | 3 |
| Dimensional drawing (Drawings) | |
| Number of positions (Drawings) | 6 |
| Rated surge voltage (Drawings) | 2.5 kV |
| Overvoltage category (Drawings) | II |
| eCl@ss 10.0.1 (Classifications) | 27440102 |
| Direction of rotation (Drawings) | Standard |
| Contact connection method (Drawings) | Solder connection |
| Rated voltage of power contact (Drawings) | 300 V |
| Thread type (Data of the insulating body) | M23 |
| Rated current for power contacts (Drawings) | 20 A |
| Type of locking (Data of the insulating body) | Screw locking |
| Housing material (Data of the insulating body) | Metal |
| Insertion/withdrawal cycles mechanical (Drawings) | 50 |
| Litz wire cross section of power contacts max. (Drawings) | 2.5 mm² |
| Litz wire cross section of power contacts min. (Drawings) | 0.08 mm² |
| Degree of protection (when plugged in) (Data of the insulating body) | IP67 |
Product Description
M23, Conect. plug. to be apar. front wall, RC, straight, shielded: yes, Screw lock, No. of poles: 6, Direction of rotation: Standard, contact type: Male, Solder connection, Flat joint, 4x Ø 3.2, codin
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Dimensional drawing
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
