QMR7/0P-0A
QMR7/0P-0A MICRO DETECTORS Photoelectric sensor Miniature cubic photoelectric diffuse, adjustment 400 mm PNP..
$0.00USD
4731 in stock
Key Specifications
Weight:52g
Emission:Red (660 nm)
Approvals:CE cULus
Dimensions:31,2x21x13mm
Supplier Information
MICRO DETECTORS
Products: 33669
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Weight | 52g |
| Emission | Red (660 nm) |
| Approvals | CE cULus |
| Dimensions | 31,2x21x13mm |
| Connections | 2m PVC cable |
| Output type | PNP |
| Load current | ≤100mA |
| LED indicators | Yellow (status output) , green (excess gain) |
| Leakage current | ≤10μA |
| Output Function | Lon/Don selectable |
| Repeat Accuracy | 5% |
| Housing Material | PA66 |
| EMC compatibility | EN 60947-5-2 |
| Operating Voltage | 10-30Vdc |
| Tightening torque | 1Nm |
| Function Principle | Diffuse reflection |
| Max ripple content | 10% |
| Output voltage drop | 2V max. IL =100 mA |
| Storage temperature | - 30°C…+ 80° C (Without freeze) |
| Switching frequency | 2kHz |
| Thermal drift of Sr | ≤10% Sr |
| Active Head Material | PMMA |
| Degree of protection | IP67 |
| Operating temperature | - 25°C…+ 70° C (Without freeze) |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 |
| No-Load supply current | ≤30mA |
| Nominal sensing distance | 400mm white target 90% Kodak 200x200mm |
| Short-circuit protection | Yes |
| Reverse Polarity Protection | Yes |
| Interference to external light | 3000lux (lampada incandescente), 10000lux (luce solare) |
| Time delay before availability | ≤200ms |
| Impulsive Overvoltage Protection | Yes |
Product Description
QMR7/0P-0A Photoelectric sensor Miniature cubicphotoelectric Diffuse adj.400 mm PNP L/D cable 2m
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
