QFRS/BN-1A
QFRS/BN-1A MICRO DETECTORS Photoelectric sensor Miniature cubic IP69K metallic AISI 316L Background Suppress..
$0.00USD
4623 in stock
Key Specifications
Weight:100g
Emission:Red (617nm)
Approvals:CE cULus, ECOLAB
Dimensions:31,4x21x11mm
Supplier Information
MICRO DETECTORS
Products: 33669
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Weight | 100g |
| Emission | Red (617nm) |
| Approvals | CE cULus, ECOLAB |
| Dimensions | 31,4x21x11mm |
| Connections | 2m PVC cable |
| Output type | NPN |
| Load current | ≤100mA |
| LED indicators | Yellow (status output) , green (power on, excess gain) |
| Leakage current | ≤100μA |
| Output Function | NO+NC |
| Repeat Accuracy | 5% |
| Housing Material | Stainless steel 316L |
| EMC compatibility | EN 60947-5-3 |
| Operating Voltage | 10-30Vdc |
| Function Principle | background suppression |
| Max ripple content | 10% |
| Output voltage drop | 2V max. IL =100 mA |
| Storage temperature | -40° ... +70°C |
| Switching frequency | 500Hz |
| Active Head Material | PPSU |
| Degree of protection | IP68, IP69K |
| Supplied Accessories | Mouting bracket screwdriver |
| Operating temperature | - 25°C…+ 60° C (Without freeze) |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 |
| No-Load supply current | ≤40mA |
| Sensitivity adjustment | Trimmer |
| Nominal sensing distance | 25...200mm |
| Short-circuit protection | Short circuit (autoreset), Overvoltage |
| Reverse Polarity Protection | Polarity inversal, Inpulsive voltage |
| Interference to external light | ≤10000lux |
| Time delay before availability | ≤30ms |
Product Description
QFRS/BN-1A Photoelectric sensor Miniature cubicIP69K Metal.AISI 316LBackground Suppression200mm.RedNPNNO +NC cable 2m
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
