In Stock Hot Product
QC 1/ 2-ST-BUS YE
QC 1/ 2-ST-BUS YE 1942002 PHOENIX CONTACT Printed-circuit board connector
$0.00USD
3032 in stock
Key Specifications
GTIN:4017918846008
Note:Made to Order (non-returnable)
Orderkey:1942002
Packing unit:50 pc
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4017918846008 |
| Note | Made to Order (non-returnable) |
| Orderkey | 1942002 |
| Packing unit | 50 pc |
| Country of origin | PL (Poland) |
| (Connection data) | CUL |
| Custom tariff number | 85366990 |
| Minimum order quantity | 50 pc |
| Pitch (Key Commercial Data) | 5 mm |
| (Standards and Regulations) | No hazardous substances above threshold values |
| Connection method (Dimensions) | Displacement connection |
| Range of articles (Dimensions) | QC 1/..-ST-BUS |
| Nominal current IN (Dimensions) | 10 A |
| Number of positions (Dimensions) | 2 |
| Dimension a (Key Commercial Data) | 5 mm |
| Width [ w ] (Key Commercial Data) | 10.9 mm |
| Height [ h ] (Key Commercial Data) | 15 mm |
| Length [ l ] (Key Commercial Data) | 29.2 mm |
| Nominal cross section (Dimensions) | 1 mm² |
| Rated voltage (III/3) (Dimensions) | 500 V |
| Weight per Piece (excluding packing) | 4.090 g |
| China RoHS (Standards and Regulations) | Environmentally friendly use period: unlimited = EFUP-e |
| Wire diameter incl. insulation (General) | 2.5 mm |
| Maximum AWG according to UL/CUL (General) | 18 |
| Minimum AWG according to UL/CUL (General) | 22 |
| Conductor cross section AWG max. (General) | 18 |
| Conductor cross section AWG min. (General) | 20 |
| Connection in acc. with standard (Dimensions) | EN-VDE |
| Conductor cross section flexible max. (General) | 1 mm² |
| Conductor cross section flexible min. (General) | 0.5 mm² |
| Connection in acc. with standard (Connection data) | EN-VDE |
Product Description
Connector for printed circuit board, nominal section: 1 mm², color: yellow, nominal current: 10 A, nominal voltage (III/2): 630 V, contact surface: Tin, contact type: Female, number of potentials: 2,
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
