PV-125A-01XL-B
PV-125A-01XL-B EATON ELECTRIC Fuse-link, high speed, 100 A, DC 1500 V, 1XL, 51 x 189 mm, gPV, IEC, UL, with ..
$0.00USD
3689 in stock
Key Specifications
Feature Name:Feature Value
Colour code (EF000931):White
Rated current (EF000227):125 A
Mounting holes (EF021553):M10
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Feature Name | Feature Value |
| Colour code (EF000931) | White |
| Rated current (EF000227) | 125 A |
| Mounting holes (EF021553) | M10 |
| Type of current (EF000143) | DC |
| Rated voltage DC (EF012281) | 1000 V |
| Breaking capacity (EF005617) | 50 kA |
| Power loss at rated current (EF012389) | 40 W |
| Type of fuse status indicator (EF004473) | Centre fuse status indicator |
| Fuse system according to IEC 60269 (EF017676) | Other |
| Centre-to-centre distance of connections (EF021151) | 157 mm |
| Utilization category according to IEC 60269 (EF002572) | gPV (photovoltaic protection) |
| Fuse construction type according to IEC 60269 (EF015865) | 01XL |
Product Description
Fuse-link, high speed, 125 A, DC 1000 V, 01XL, gPV, UL, IEC, bolted connection
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
