PTDA 2,5/ 2-PH-5,0 BU
PTDA 2,5/ 2-PH-5,0 BU 1773727 PHOENIX CONTACT PTDA 2,5/ 2-PH-5,0 BU
$0.00USD
3732 in stock
Key Specifications
EAN:Four trillion forty six billion three hundred fifty six million four hundred seventy six thousand three hundred eighty six
Key order:One million seven hundred seventy three thousand seven hundred twenty seven
Key selling:AACHBA -
Packing unit:250 pcs
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | Four trillion forty six billion three hundred fifty six million four hundred seventy six thousand three hundred eighty six |
| Key order | One million seven hundred seventy three thousand seven hundred twenty seven |
| Key selling | AACHBA - |
| Packing unit | 250 pcs |
| UNSPSC 11 (ETIM) | Thirty four million one hundred thirty one thousand two hundred three |
| Country of origin | PL (Poland) |
| ETIM 3.0 (eCl@ss) | EC001121 |
| ETIM 4.0 (eCl@ss) | EC002643 |
| ETIM 5.0 (eCl@ss) | EC002638 |
| ETIM 6.0 (eCl@ss) | EC002638 |
| ETIM 7.0 (eCl@ss) | EC002638 |
| (Data connection) | CUL |
| UNSPSC 13.2 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred nine |
| UNSPSC 6.01 (ETIM) | Thirty million two hundred eleven thousand eight hundred one |
| UNSPSC 12.01 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| Tariff number tariff | Eighty five million three hundred sixty six thousand nine hundred ninety |
| UNSPSC 7.0901 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| eCl@ss 4.0 (Ratings) | Twenty seven million one hundred forty one thousand one hundred eleven |
| eCl@ss 4.1 (Ratings) | Twenty seven million one hundred forty one thousand one hundred nine |
| eCl@ss 5.0 (Ratings) | Twenty seven million one hundred forty one thousand one hundred ninety |
| eCl@ss 5.1 (Ratings) | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 6.0 (Ratings) | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 7.0 (Ratings) | Twenty seven million four hundred forty thousand three hundred nine |
| eCl@ss 8.0 (Ratings) | Twenty seven million four hundred forty thousand three hundred nine |
| eCl@ss 9.0 (Ratings) | Twenty seven million four hundred forty thousand three hundred nine |
| Minimum order quantity | 250 pcs |
| Step (Data commercial) | 5 mm |
| Average (Data commercial) | 5 mm |
| Number of poles (Dimensions) | Two |
| Width [ w ] (Data commercial) | 11.4 |
| Height [ h ] (Data commercial) | 16 mm |
| Length [ l ] (Data commercial) | 20 mm |
| (Standards and specifications) | No dangerous substances above the thresholds |
| Family of articles (Dimensions) | PTDA 2,5/..-PH |
| Nominal current IN (Dimensions) | 13.5 To |
| Type of connection (Dimensions) | Connection by spring loaded push-in |
| Unit weight (excluding packaging) | 3,694 g |
| Nominal cross section (Dimensions) | 2.5 mm2 |
| AWG according to UL/CUL max. (Overview) | Fourteen |
| AWG according to UL/CUL min. (Overview) | Twenty four |
| Tension and sizing (III/3) (Dimensions) | 320 V |
| Core cross-section rigid min. (Overview) | 0,2 mm2 |
| Section of conductor AWG max. (Overview) | Fourteen |
| Section of conductor AWG min. (Overview) | Twenty four |
| China RoHS (Standards and specifications) | Space of time for the intended use: unlimited = FEUP-e |
| Section of conductor rigid max. (Overview) | 2.5 mm2 |
| Connection according to standard (Dimensions) | EN-VDE |
| Section of flexible conductor max. (Overview) | 2.5 mm2 |
| Section of flexible conductor, min. (Overview) | 0,2 mm2 |
| Connection according to standard (Data connection) | EN-VDE |
| 2 conductors with same cross section, rigid max. (Overview) | 2.5 mm2 |
| 2 conductors with same cross section, rigid min. (Overview) | 0,2 mm2 |
| 2 conductors with same cross section, flexible max. (Overview) | 2.5 mm2 |
| 2 conductors with same cross section, flexible, min. (Overview) | 0,2 mm2 |
| Section of flexible conductor with toe, with plastic sleeve max. (Overview) | 1 mm2 |
| Section of flexible conductor with toe, with plastic sleeve min. (Overview) | 0.5 mm2 |
| Section of flexible conductor with toe cap, without plastic sleeve max. (Overview) | 2.5 mm2 |
| Section of flexible conductor with toe cap, without plastic sleeve min. (Overview) | 0.5 mm2 |
| 2 conductors with same cross section, flexible with AEH without plastic sleeve max. (Overview) | 2.5 mm2 |
| 2 conductors with same cross section, flexible with AEH without plastic sleeve min. (Overview) | 0.5 mm2 |
| 2 conductors with same cross section, flexible with TWIN-AEH with plastic sleeve max. (Overview) | 1 mm2 |
| 2 conductors with same cross section, flexible with TWIN-AEH with plastic sleeve min. (Overview) | 0.5 mm2 |
Product Description
Connector for printed circuit board, nominal section: 2.5 mm², color: blue, nominal current: 14 A, nominal voltage (III/2): 400 V, contact surface: Tin, contact type: Female, number of rows: 1, number
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Connector for printed circuit board, number of poles: 2, pitch: 5 mm, color: blue
