PT 1,5/ 4-PH-3,5 BD:-E4
PT 1,5/ 4-PH-3,5 BD:-E4 1715337 PHOENIX CONTACT PCB terminal block
$0.00USD
4998 in stock
Key Specifications
GTIN:4055626407067
Orderkey:1715337
Packing unit:1
Custom tariff number:85366990
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4055626407067 |
| Orderkey | 1715337 |
| Packing unit | 1 |
| Custom tariff number | 85366990 |
| Screw thread (Dimensions) | M2 |
| Pitch (Key Commercial Data) | 3.5 mm |
| (Standards and Regulations) | For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
| Connection method (Dimensions) | Screw connection with wire protector |
| Range of articles (Dimensions) | PT 1,5/..-PH |
| Nominal current IN (Dimensions) | 8 A |
| Number of positions (Dimensions) | 4 |
| Dimension a (Key Commercial Data) | 10.5 mm |
| Height [ h ] (Key Commercial Data) | 11 mm |
| Length [ l ] (Key Commercial Data) | 12.9 mm |
| Nominal cross section (Dimensions) | 1.5 mm² |
| Rated voltage (III/2) (Dimensions) | 200 V |
| China RoHS (Standards and Regulations) | Environmentally Friendly Use Period = 50 |
| Insulating material group (Dimensions) | I |
| Flammability rating according to UL 94 (General) | V0 |
| Flammability rating according to UL 94 (Dimensions) | V0 |
Product Description
Connector for printed circuit board, nominal section: 1.5 mm², color: green, rated current: 8 A, sizing voltage (III/2): 200 V, surface contacts: Tin, contact type: Connection female, Number of potent
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
