In Stock Hot Product
PM-15-15
PM-15-15 MEANWELL AC-DC Single output Medical Encapsulated power supply, Output 15VDC / 1A, PCB mount, 2xMOPP
$0.00USD
4718 in stock
Key Specifications
Name:PM-15-15
Format:For Printed Circuit
Series:PM-15
Approvals:CE, UL
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | PM-15-15 |
| Format | For Printed Circuit |
| Series | PM-15 |
| Approvals | CE, UL |
| Power (W) | 15,00 |
| Subformato | Encapsulated |
| Width (mm) | 53.00 |
| Height (mm) | 22.70 |
| AC input Max | 264,00 |
| AC input Min | 85,00 |
| Applications | Industrial, Medical, Telecommunications |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Isolation (V) | 4.000,00 |
| Output voltage | 15,00 |
| Peak Power (W) | Fifteen |
| Input connector | Pin |
| Input frequency | 50 Hz, 60 Hz, 440 Hz |
| Long/Background | 75.00 |
| Long Description | Switching Power supply for Printed Circuit board.Range of universal Input85-264vac47-440Hz.Output voltage15vdc.Output intensity1A. Range of output current 0-1A according to demand load.Power:15W.Source certified for medical applications 2xMOPP(the patient protection).Consumption without load <0.5 W.Entry of class II non-grounded.Efficiency:79%.Working temperature: from-20up+70ºCof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:75 x 53 x 22,7.3 years of warranty.Manufacturer: MEAN WELL.The PM series are sources compact encapsulated for mounting on a printed circuit board for applications for medical, industrial, or information technology.Are cerificadas under regulations in health protection for the patient and can be used in the most demanding applications BF, with due considerations of the system.Have a low consumption at no load and high reliability. |
| Output connector | Pin |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 3,00 |
| Country of Origin | Taiwan |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Switching Power supply for Printed Circuit board.
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
