PLM-40-1400
PLM-40-1400 MEANWELL AC-DC Single output LED driver Constant Current (CC), Input range 110-295VAC, Output 1...
$0.00USD
4029 in stock
Key Specifications
Name:PLM-40-1400
State:Do not Use for New Designs
Format:Box
Series:PLM-40
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | PLM-40-1400 |
| State | Do not Use for New Designs |
| Format | Box |
| Series | PLM-40 |
| Approvals | CCC, CE, ENEC, UL |
| Power (W) | 40,60 |
| Subformato | IP30 |
| Width (mm) | 42.00 |
| Height (mm) | 24.00 |
| AC input Max | 295,00 |
| AC input Min | 110,00 |
| Applications | Lighting |
| Manufacturer | MEAN WELL |
| Product type | LED Driver |
| Isolation (V) | 3.750,00 |
| Peak Power (W) | 40.6 |
| Input connector | Screw-Type |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 175.00 |
| Long Description | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in plastic boxIP30.Input range110-295Vca47-63Hz.Output in constant current1400mA.Range of output voltage with current mode constant15 to 29Vccaccording to demand load.Power:40,6 W.Efficiency typical:86%.Input class II without grounding.Factor corrector, power>0.95to 230vac at full load.Consumption without load<0.5 W.Operating temperature range of caseTcfrom-30ºCup+45ºC.Dimensions (Length x Width x Height):175 x 42 x 24mm.2 years of warranty.Manufacturer: MEAN WELL.The serial PLM are LED drivers designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current.With plastic housing, the serial PLM has a small and compact size. Connection is by screw and protection, anti-pull, without the need of put terminals to make the connections. With ventilation for free circulation of air. With active PFC and high reliability at low cost. Indicated for interior applications, lighting, office, LED lighting and signalling mobile (roads, screens). Complies with all regulations of lighting. |
| Output connector | Screw-Type |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 2,00 |
| Country of Origin | China |
| Output current mA | One thousand four hundred |
| Intensity of Minimum Output (mA) | 1.400,00 |
| Intensity of Output Maximum (mA) | 1.400,00 |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
LED driver.
