PLH 16/ 3-10-ZB
PLH 16/ 3-10-ZB 1702720 PHOENIX CONTACT PCB terminal block
$0.00USD
3151 in stock
Key Specifications
GTIN:4046356609708
Orderkey:1702720
Packing unit:1
Custom tariff number:85369010
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4046356609708 |
| Orderkey | 1702720 |
| Packing unit | 1 |
| Custom tariff number | 85369010 |
| Pitch (Key Commercial Data) | 10 mm |
| (Standards and Regulations) | No hazardous substances above threshold values |
| Stripping length (Dimensions) | 18 mm |
| Range of articles (Dimensions) | PLH 16/ |
| Nominal current IN (Dimensions) | 76 A |
| Solder pin surface (Dimensions) | |
| Number of positions (Dimensions) | 3 |
| Dimension a (Key Commercial Data) | 20 mm |
| Pin spacing (Key Commercial Data) | 12.5 mm |
| Rated voltage (II/2) (Dimensions) | 800 V |
| Nominal cross section (Dimensions) | 16 mm² |
| Rated voltage (III/2) (Dimensions) | 400 V |
| Rated voltage (III/3) (Dimensions) | 400 V |
| Hole diameter (Key Commercial Data) | 1.6 mm |
| Solder pin [P] (Key Commercial Data) | 4.5 mm |
| China RoHS (Standards and Regulations) | Environmentally friendly use period: unlimited = EFUP-e |
| Rated surge voltage (II/2) (Dimensions) | 4 kV |
| Rated surge voltage (III/2) (Dimensions) | 4 kV |
| Rated surge voltage (III/3) (Dimensions) | 4 kV |
| Conductor cross section AWG max. (General) | 4 |
| Conductor cross section AWG min. (General) | 18 |
| Connection in acc. with standard (Connection data) | UL |
| 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max. (General) | 4 mm² |
| 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min. (General) | 0.75 mm² |
