PLD-60-2000B
PLD-60-2000B MEANWELL AC-DC Single output LED driver Constant Current (CC), Input 230VAC, Output 2.0A / 18-3..
$0.00USD
3677 in stock
Key Specifications
Name:PLD-60-2000B
Format:Box
Series:PLD-60
Approvals:CE, ENEC
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | PLD-60-2000B |
| Format | Box |
| Series | PLD-60 |
| Approvals | CE, ENEC |
| Power (W) | 60,00 |
| Subformato | IP42 |
| Width (mm) | 60.00 |
| Height (mm) | 31.50 |
| AC input Max | 295,00 |
| AC input Min | 180,00 |
| Applications | Lighting |
| Manufacturer | MEAN WELL |
| Product type | LED Driver |
| Isolation (V) | 3.750,00 |
| Peak Power (W) | Sixty |
| Input connector | Cable |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 128.00 |
| Long Description | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in plastic boxIP42.Input range180-295Vca47-63Hz.Output in constant current2000mA.Range of output voltage with current mode constant18 to 30vdcaccording to demand load.Power:60W.Efficiency typical:86%.Input class II without grounding.Factor corrector, power>0,9to 230vac at full load.Operating temperature range of caseTcfrom-30ºCup+45ºC.Dimensions (Length x Width x Height):128 x 60 x 31.5 mm3 years of warranty.Manufacturer: MEAN WELL.The series PLD are LED drivers designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.With plastic housing, suitable for LED applications in interior.Protection against excess temperature and short circuit.Have a low cost and a high reliability. |
| Output connector | Cable |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 3,00 |
| Country of Origin | China |
| Output current mA | Two thousand |
| Intensity of Minimum Output (mA) | 2.000,00 |
| Intensity of Output Maximum (mA) | 2.000,00 |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
LED driver.
