PLC-VT/ACT
PLC-VT/ACT 2295567 PHOENIX CONTACT Feed-through terminal block
$0.00USD
3225 in stock
Key Specifications
GTIN:4017918821852
Orderkey:2295567
Catalog page:Page 546 (C-5-2017)
Packing unit:10 pc
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4017918821852 |
| Orderkey | 2295567 |
| Catalog page | Page 546 (C-5-2017) |
| Packing unit | 10 pc |
| Country of origin | DE (Germany) |
| Custom tariff number | 85369010 |
| (Ambient conditions) | 6 A (per connection terminal block with jumper location) |
| Minimum order quantity | 10 pc |
| Screw thread (General) | M3 |
| Connection name (General) | Supply |
| Stripping length (General) | 8 mm |
| Connection method (General) | Screw connection |
| Depth (Key Commercial Data) | 94 mm |
| Width (Key Commercial Data) | 6.2 mm |
| (Standards and Regulations) | For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
| Height (Key Commercial Data) | 80 mm |
| Number of connections (General) | 1 |
| (Connection data for connection 1) | IEC 60664 |
| Status display (Ambient conditions) | No |
| Weight per Piece (excluding packing) | 27.640 g |
| Conductor cross section AWG (General) | 24 ... 12 |
| China RoHS (Standards and Regulations) | Environmentally Friendly Use Period = 50 |
| Mounting position (Ambient conditions) | any |
| Conductor cross section solid (General) | 0.2 mm² ... 4 mm² |
| Degree of protection (Ambient conditions) | IP20 |
| Assembly instructions (Ambient conditions) | In rows with zero spacing |
| Conductor cross section flexible (General) | 0.2 mm² ... 2.5 mm² |
| Connection in acc. with standard (General) | IEC / EN |
| Ambient temperature (operation) (Dimensions) | -40 °C ... 70 °C |
| Max. perm. operating voltage (Ambient conditions) | 250 V AC/DC |
| Ambient temperature (storage/transport) (Dimensions) | -40 °C ... 70 °C |
| Max. perm. current (per branch) (Ambient conditions) | 6 A (per signal conductor) |
| Degree of pollution (Connection data for connection 1) | 2 |
| Rated surge voltage (Connection data for connection 1) | 2.3 kV (Functional insulation) |
| Overvoltage category (Connection data for connection 1) | II |
| Standards/regulations (Connection data for connection 1) | DIN EN 50178 |
| Rated insulation voltage (Connection data for connection 1) | 260 V AC |
| Connection in acc. with standard (Connection data for connection 1) | CUL |
| Flammability rating according to UL 94 (Connection data for connection 1) | V0 |
Product Description
VARIOFACE feed-through terminal block (3-conductor screw connection), for PLC-INTERFACE actuator series
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
