PLC-SP-S/H
PLC-SP-S/H 2980746 PHOENIX CONTACT Switch
$0.00USD
3086 in stock
Key Specifications
GTIN:4046356051484
Note:Made to Order (non-returnable)
Orderkey:2980746
Catalog page:Page 431 (C-7-2015)
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4046356051484 |
| Note | Made to Order (non-returnable) |
| Orderkey | 2980746 |
| Catalog page | Page 431 (C-7-2015) |
| Packing unit | 10 pc |
| Country of origin | DE (Germany) |
| Custom tariff number | 85364900 |
| Connection name (General) | Input side |
| Stripping length (General) | 8 mm |
| Connection method (General) | Spring-cage connection |
| Depth (Key Commercial Data) | 90 mm |
| Width (Key Commercial Data) | 6.2 mm |
| (Standards and Regulations) | For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
| Height (Key Commercial Data) | 80 mm |
| (Connection data input side) | EN 50178 |
| Operating mode (Contact side) | 100% operating factor |
| Net weight (SAP) (Contact side) | 25.935 g |
| Mounting position (Contact side) | any |
| Assembly instructions (Contact side) | In rows with zero spacing |
| Weight per Piece (excluding packing) | 25.940 g |
| Conductor cross section AWG (General) | 26 ... 14 |
| China RoHS (Standards and Regulations) | Environmentally Friendly Use Period = 50 |
| Conductor cross section solid (General) | 0.14 mm² ... 2.5 mm² |
| Insulation (Connection data input side) | Basic insulation |
| Conductor cross section flexible (General) | 0.14 mm² ... 2.5 mm² |
| Maximum inrush current (Ambient conditions) | 50 mA |
| Min. switching current (Ambient conditions) | 1 mA |
| Ambient temperature (operation) (Dimensions) | -20 °C ... 60 °C |
| Maximum switching voltage (Ambient conditions) | 72 V DC |
| Minimum switching voltage (Ambient conditions) | 2 V DC |
| Degree of pollution (Connection data input side) | 2 |
| Rated surge voltage (Connection data input side) | 0.5 kV |
| Overvoltage category (Connection data input side) | III |
| Standards/regulations (Connection data input side) | IEC 60664 |
| Ambient temperature (storage/transport) (Dimensions) | -40 °C ... 70 °C |
| Rated insulation voltage (Connection data input side) | 85 V AC |
| Connection in acc. with standard (Connection data input side) | CUL |
| Flammability rating according to UL 94 (Connection data input side) | V0 |
