PLA 5/ 2-7,5-ZF BK
PLA 5/ 2-7,5-ZF BK 1847025 PHOENIX CONTACT PCB terminal block
$0.00USD
4201 in stock
Key Specifications
GTIN:4055626002934
Orderkey:1847025
Packing unit:1
(Connection data):No hazardous substances above threshold values
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4055626002934 |
| Orderkey | 1847025 |
| Packing unit | 1 |
| (Connection data) | No hazardous substances above threshold values |
| Custom tariff number | 85369010 |
| Pitch (Key Commercial Data) | 7.5 mm |
| China RoHS (Connection data) | Environmentally friendly use period: unlimited = EFUP-e |
| Stripping length (Dimensions) | 12 mm |
| Range of articles (Dimensions) | PLA 5/ |
| Nominal current IN (Dimensions) | 41 A |
| Solder pin surface (Dimensions) | |
| Insulating material (Dimensions) | PA |
| Number of positions (Dimensions) | 2 |
| Dimension a (Key Commercial Data) | 7.5 mm |
| Pin spacing (Key Commercial Data) | 12.5 mm |
| Rated voltage (II/2) (Dimensions) | 1000 V |
| Nominal cross section (Dimensions) | 6 mm² |
| Rated voltage (III/2) (Dimensions) | 1000 V |
| Rated voltage (III/3) (Dimensions) | 1000 V |
| Hole diameter (Key Commercial Data) | 1.6 mm |
| Solder pin [P] (Key Commercial Data) | 3.6 mm |
| Rated surge voltage (II/2) (Dimensions) | 6 kV |
| Rated surge voltage (III/2) (Dimensions) | 8 kV |
| Rated surge voltage (III/3) (Dimensions) | 8 kV |
| Conductor cross section AWG max. (General) | 10 |
| Conductor cross section AWG min. (General) | 24 |
| Conductor cross section solid max. (General) | 6 mm² |
| Conductor cross section solid min. (General) | 0.2 mm² |
| Conductor cross section flexible max. (General) | 6 mm² |
| Conductor cross section flexible min. (General) | 0.2 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve max. (General) | 6 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve min. (General) | 0.2 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve max. (General) | 6 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve min. (General) | 0.2 mm² |
| 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max. (General) | 2.5 mm² |
| 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min. (General) | 0.5 mm² |
Product Description
Terminal block for printed circuit board, nominal current: 41 A, dimensioning voltage (III/2): 1000 V, nominal cross-section: 6 mm², number of potentials: 2, number of rows: 1, number of poles per row
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
