In Stock Hot Product
PCV 4/ 4-GF-7,62 BG
PCV 4/ 4-GF-7,62 BG 1712584 PHOENIX CONTACT Printed-circuit board connector
$0.00USD
4326 in stock
Key Specifications
GTIN:4046356086332
Note:Made to Order (non-returnable)
Orderkey:1712584
Packing unit:50 pc
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4046356086332 |
| Note | Made to Order (non-returnable) |
| Orderkey | 1712584 |
| Packing unit | 50 pc |
| Country of origin | DE (Germany) |
| Color (Dimensions) | Pebble gray |
| Custom tariff number | 85366930 |
| Minimum order quantity | 50 pc |
| Pitch (Key Commercial Data) | 7.62 mm |
| (Standards and Regulations) | No hazardous substances above threshold values |
| Height (Key Commercial Data) | 29 mm |
| Range of articles (Dimensions) | PCV 4/..-G |
| Nominal current IN (Dimensions) | 20 A |
| Number of positions (Dimensions) | 4 |
| Dimension a (Key Commercial Data) | 22.86 mm |
| Rated voltage (III/3) (Dimensions) | 400 V |
| Pin dimensions (Key Commercial Data) | 1 x 0.8 mm |
| Weight per Piece (excluding packing) | 12.430 g |
| China RoHS (Standards and Regulations) | Environmentally friendly use period: unlimited = EFUP-e |
| Connection in acc. with standard (General) | EN-VDE |
| Connection in acc. with standard (Dimensions) | EN-VDE |
| Length of the solder pin (Key Commercial Data) | 5 mm |
Product Description
Printed circuit board base housing, nominal section: 4 mm², color: pebble gray, nominal current: 20 A, nominal voltage (III/2): 630 V, contact surface: Tin, contact type: Male, number of potentials: 4
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
