PCC 4/ 3-ST-7,62 BK
PCC 4/ 3-ST-7,62 BK 1731866 PHOENIX CONTACT Printed-circuit board connector
$0.00USD
4113 in stock
Key Specifications
GTIN:4046356158503
Note:Made to Order (non-returnable)
Orderkey:1731866
Packing unit:50 pc
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4046356158503 |
| Note | Made to Order (non-returnable) |
| Orderkey | 1731866 |
| Packing unit | 50 pc |
| Country of origin | DE (Germany) |
| (Connection data) | CSA |
| Custom tariff number | 85366990 |
| Minimum order quantity | 50 pc |
| Pitch (Key Commercial Data) | 7.62 mm |
| (Standards and Regulations) | No hazardous substances above threshold values |
| Connection method (Dimensions) | Crimp connection |
| Range of articles (Dimensions) | PCC 4/..-ST |
| Nominal current IN (Dimensions) | 20 A |
| Number of positions (Dimensions) | 3 |
| Dimension a (Key Commercial Data) | 15.24 mm |
| Nominal cross section (Dimensions) | 4 mm² |
| Rated voltage (III/3) (Dimensions) | 400 V |
| Weight per Piece (excluding packing) | 2.970 g |
| China RoHS (Standards and Regulations) | Environmentally friendly use period: unlimited = EFUP-e |
| Maximum AWG according to UL/CUL (General) | 14 |
| Minimum AWG according to UL/CUL (General) | 20 |
| Conductor cross section AWG max. (General) | 14 |
| Conductor cross section AWG min. (General) | 20 |
| Connection in acc. with standard (Dimensions) | EN-VDE |
| Conductor cross section flexible max. (General) | 2.5 mm² |
| Conductor cross section flexible min. (General) | 0.5 mm² |
| Connection in acc. with standard (Connection data) | EN-VDE |
Product Description
Connector for printed circuit board, nominal section: 4 mm², color: black, nominal current: 20 A, nominal voltage (III/2): 1000 V, contact surface: Tin, contact type: Female, number of potentials: 3,
