PC1/AN-3F
PC1/AN-3F MICRO DETECTORS Inductive sensor Ø4 mm NO/NPN Sensing distance 1,5 mm plug M8
$0.00USD
3760 in stock
Key Specifications
Weight:55g
Mounting:Flush
Dimensions:M18 x 1 / L = 63,1 mm
Hysteresis:1 ... 20%
Supplier Information
MICRO DETECTORS
Products: 33669
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Weight | 55g |
| Mounting | Flush |
| Dimensions | M18 x 1 / L = 63,1 mm |
| Hysteresis | 1 ... 20% |
| Connections | M12 Connector |
| Output type | NPN |
| Load current | ≤ 200mA |
| Exit function | NOT |
| Nominal range | 5mm |
| Repeatability | 5% (UB 24V Ta=23°C ±5°C) |
| Thermal drift | < 10% |
| body material | stainless steel AISI 316L |
| Certifications | CEcULus |
| LED indicators | Yellow LED output status |
| Supply voltage | 10 - 30vdc |
| Leakage current | ≤ 10µA |
| Operating range | 0...4mm |
| Object reference | 18x18mm FE360 |
| Correction Factor | copper: 0,25 / aluminum: 0,35 / brass: 0,40 / stainless steel: 0,70 |
| Tightening torque | 50Nm |
| Shock and vibration | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 |
| Switching frequency | 1.5 kHz |
| Accessories included | 2 nuts M18x1 |
| Degree of protection | IP 67 (EN60529) - IP68 (1m, 7 days) - IP69K |
| Operating temperature | -40°C...+80°C (up to 100 ° c short exposure in processes of sanitation) |
| Maximum residual ripple | ≤10% |
| Protection short circuit | Yes |
| Delay to the availability | 50ms |
| Voltage drop to the output | ≤ 2V @200mA |
| Protection polarity reversal | Yes |
| Electromagnetic compatibility | IEC 60947-5-2 |
| Material of the active surface | PPS |
| Protection against inductive loads | Yes |
| Absorption of current in the vacuum | ≤ 15mA |
