In Stock Hot Product
P2RF LABEL
P2RF LABEL 188202 OMRON Basis for relay, Label P2RF (100pcs)
$0.00USD
3650 in stock
Key Specifications
Item (Compact, Multi-function Timers with Plug-in socket):H3RN-1-B/H3RN-2-B
Type (Compact, Multi-function Timers with Plug-in socket):Timer
12 VDC (Compact, Multi-function Timers with Plug-in socket):H3RN-2-B DC12
24 VDC (Compact, Multi-function Timers with Plug-in socket):H3RN-2-B DC24
Supplier Information
OMRON
Products: 41472
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Item (Compact, Multi-function Timers with Plug-in socket) | H3RN-1-B/H3RN-2-B |
| Type (Compact, Multi-function Timers with Plug-in socket) | Timer |
| 12 VDC (Compact, Multi-function Timers with Plug-in socket) | H3RN-2-B DC12 |
| 24 VDC (Compact, Multi-function Timers with Plug-in socket) | H3RN-2-B DC24 |
| DPST-NO (Compact, Multi-function Timers with Plug-in socket) | 24 VAC |
| Pin type (Compact, Multi-function Timers with Plug-in socket) | Plug-in |
| Reset time (Compact, Multi-function Timers with Plug-in socket) | Min. power-opening time: 12, 24 VDC: 0.1 s max. (including halfway reset)24 VAC: 0.5 s max. (including halfway reset) |
| Time ranges (Compact, Multi-function Timers with Plug-in socket) | 0.1 s to 10 min (1 s, 10 s, 1 min, or 10 min max. selectable) |
| Reset voltage (Compact, Multi-function Timers with Plug-in socket) | 10% max. of rated supply voltage |
| Setting error (Compact, Multi-function Timers with Plug-in socket) | ±15% ±50 ms FS max. |
| H3RN-2-B/-21-B (Compact, Multi-function Timers with Plug-in socket) | P2RF-08-PU |
| Operating mode (Compact, Multi-function Timers with Plug-in socket) | ON-delay, interval, flicker OFF-start, or flicker-ON start selectable by DIP switch |
| Control outputs (Compact, Multi-function Timers with Plug-in socket) | 3 A at 250 VAC, resistive load (cosφ = 1) (G6B-2_14P-FD-US used (Contact materials: AgSnIn))The minimum applicable load is 10 mA at 5 VDC (P reference value). |
| Operating modes (Compact, Multi-function Timers with Plug-in socket) | Control output |
| Ambient temperature (Compact, Multi-function Timers with Plug-in socket) | Operating: −10°C to 55°C (with no icing)Storage: −25°C to 65°C (with no icing) |
| Degree of protection (Compact, Multi-function Timers with Plug-in socket) | IP40 (Terminal screw sections are excluded.) |
| Influence of voltage (Compact, Multi-function Timers with Plug-in socket) | ±2% FS max. |
| Rated supply voltage1 (Compact, Multi-function Timers with Plug-in socket) | 24 VAC (50/60 Hz); 12, 24 VDC |
| Operating voltage range (Compact, Multi-function Timers with Plug-in socket) | 85% to 110% of rated supply voltage (12 VDC: 90% to 110% of rated supply voltage)2 |
| Influence of temperature (Compact, Multi-function Timers with Plug-in socket) | ±2% FS max. |
| Size in mm (H × W × D) (Compact, Multi-function Timers with Plug-in socket) | 31.2×12.8×47.2 |
| Accuracy of operating time (Compact, Multi-function Timers with Plug-in socket) | ±1% FS max. (1 s range: ±1%±10 ms max.) |
| Short-time range (0.1 s to 10 min) (Compact, Multi-function Timers with Plug-in socket) | Long-time range (0.1 m to 10 h) |
| Screwless socket with Push-in plustechnology (Compact, Multi-function Timers with Plug-in socket) | H3RN-1-B/-11-B |
| On-delay, Interval,Flicker OFF-start, Flicker ON Start (Compact, Multi-function Timers with Plug-in socket) | SPDT |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Operating modes
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
