OT200KLAA6BZ
OT200KLAA6BZ 1SCA022717R9520 ABB OT200KLAA6BZ Enclosed switch
$0.00USD
4129 in stock
Key Specifications
:(690 V) 200 A
ETIM 7:EC000216 - Switch disconnector
ETIM 8:EC000216 - Switch disconnector
Standards:IEC 60947-1, -3
Supplier Information
ABB
Products: 44170
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| (690 V) 200 A | |
| ETIM 7 | EC000216 - Switch disconnector |
| ETIM 8 | EC000216 - Switch disconnector |
| Standards | IEC 60947-1, -3 |
| Power Loss | at Rated Operating Conditions per Pole 4 W |
| Handle Type | Pistol handle |
| RoHS Status | Following EU Directive 2011/65/EU |
| Handle Color | Black |
| WEEE Category | 4. Large Equipment (Any External Dimension More Than 50 cm) |
| Number of Poles | 6 |
| Pollution Degree | 3 |
| RoHS Information | 1SCC340049D0202 |
| Country of Origin | Finland (FI) |
| Product Net Width | 800 mm |
| Enclosure Material | Steel sheet |
| Product Net Height | 600 mm |
| Product Net Weight | 24.5 kg |
| Mechanical Drawings | OTKM608023PO.stp |
| Package Level 1 EAN | 6417019230238 |
| Cable Entry Position | Up/Down |
| Degree of Protection | acc. to IEC 60529 IP65 |
| Customs Tariff Number | 85363090 |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 815 mm |
| Cable Outlets Per Side | Open / Open |
| Minimum Order Quantity | 1 piece |
| Package Level 1 Height | 325 mm |
| Instructions and Manuals | 1SCC340005M0007 |
| Rated Operational Voltage | Main Circuit 1000 V |
| Mounted Auxiliary Contacts | 0 NO, 0 NC |
| Object Classification Code | Q |
| Product Net Depth / Length | 230 mm |
| Package Level 1 Gross Weight | 29 kg |
| Replacement Product ID (NEW) | OT200KLUU6BZ |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 1000 V |
| Declaration of Conformity - CE | 1SCC340025D2704 |
| Package Level 1 Depth / Length | 910 mm |
| Connecting Capacity Main Circuit | Hole Diameter 8 mm |
| Data Sheet, Technical Information | 1SCC340015C0201 |
| Maximum Mounted Auxiliary Contacts | 4 NO, 2 NC |
| Conventional Thermal Current (Ithe) | Fully Enclosed 200 A |
| Rated Operational Power AC-23A (Pe) | (380 ... 415 V) 110 kW |
| Rated Operational Current AC-22A (Ie) | (380 ... 415 V) 200 A |
| Rated Operational Current AC-23A (Ie) | (380 ... 415 V) 200 A |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Short-Circuit Making Capacity (Icm) | (1000 V AC) 30 kA |
| Rated Conditional Short-Circuit Current (Inc) | 40.5 kA |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 1 s 8 kA |
Product Description
Int. Box disconnector OT200KLAA6BZ
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
