In Stock Hot Product
NX-DA3203
NX-DA3203 NX029092D 686023 OMRON NX Unit 4 Analog Outputs 4-20mA 1/8000 250μs
$400.21USD
66 in stock
Key Specifications
():NX-AUX02
Depth:71 mm
Width:12 mm
Height:100 mm
Supplier Information
OMRON
Products: 41472
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| () | NX-AUX02 |
| Depth | 71 mm |
| Width | 12 mm |
| Height | 100 mm |
| Weight | 70 g |
| I/O system | NX I/O Bus |
| IO link master | |
| Type of module | Analog I/O |
| Conversion time | 1 ms/unit |
| Signal processing | Free running |
| Input circuit type | None |
| I/O connection type | Push-in |
| Temperature input type | None |
| Number of analog inputs | 0 |
| Detachable I/O connector | |
| Linear analog input type | None |
| Number of I/O connectors | 1 |
| Number of analog outputs | 4 |
| Degree of protection (IP) | IP20 |
| Linear analog output type | 4 to 20 mA |
| SIL according to IEC 61508 | None |
| Suitable for safety functions | |
| Resolution of the analog outputs | 13 Bit |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
