MSTBVA 2,5/ 4-G THT
MSTBVA 2,5/ 4-G THT 1941029 PHOENIX CONTACT Printed-circuit board connector
$0.00USD
4655 in stock
Key Specifications
Type:Component suitable for through hole reflow
Color:black
Pitch:5 mm
Width:22 mm
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Type | Component suitable for through hole reflow |
| Color | black |
| Pitch | 5 mm |
| Width | 22 mm |
| Height | 15.9 mm |
| Length | 8.6 mm |
| Pin layout | Linear pinning |
| Product type | PCB headers |
| Hole diameter | 1.4 mm |
| Mounting type | THR soldering |
| Product family | MSTBVA 2,5/..-G-THT |
| Contact surface | Tin Sn |
| Mounting flange | without |
| Article revision | 03 |
| Installed height | 12 mm |
| Type of packaging | packed in cardboard |
| Dimensional drawing | |
| Insulating material | PA |
| Number of positions | 4 |
| Maximum load current | 12 A |
| Outer packaging type | Dry bag |
| Rated voltage (II/2) | 400 V |
| Rated voltage (III/2) | 320 V |
| Contact surface material | Sn |
| Length of the solder pin | 3.9 mm |
| Insulating material group | IIIa |
| Rated surge voltage (II/2) | 4 kV |
| Rated surge voltage (III/2) | 4 kV |
| Rated surge voltage (III/3) | 4 kV |
| Flammability rating according to UL 94 | V0 |
Product Description
PCB headers, number of positions: 4, product range: MSTBVA 2,5/..-G-THT, pitch: 5 mm, pin layout: Linear pinning, solder pin [P]: 3.9 mm, type of packaging: packed in cardboard, For user information a
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
