MSTBVA 2,5/ 2-G YE
MSTBVA 2,5/ 2-G YE 1709064 PHOENIX CONTACT Printed-circuit board connector
$0.00USD
3055 in stock
Key Specifications
GTIN:4055626042756
Orderkey:1709064
(Drawings):
Packing unit:1
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4055626042756 |
| Orderkey | 1709064 |
| (Drawings) | |
| Packing unit | 1 |
| Pitch (Drawings) | 5 mm |
| Width (Drawings) | 12 mm |
| ETIM 5.0 (eCl@ss) | EC002637 |
| ETIM 6.0 (eCl@ss) | EC002637 |
| ETIM 7.0 (eCl@ss) | EC002637 |
| Height (Drawings) | 12 mm |
| Length (Drawings) | 8.57 mm |
| Color (Dimensions) | yellow |
| UNSPSC 13.2 (ETIM) | 39121409 |
| UNSPSC 19.0 (ETIM) | 39121409 |
| Custom tariff number | 85366930 |
| Dimension a (Drawings) | 5 mm |
| Width [ w ] (Drawings) | 12 mm |
| Height [ h ] (Drawings) | 15.9 mm |
| Length [ l ] (Drawings) | 8.57 mm |
| Pin dimensions (Drawings) | 1 x 1 mm |
| (Standards and Regulations) | No hazardous substances above threshold values |
| eCl@ss 5.1 (Classifications) | 27260700 |
| eCl@ss 6.0 (Classifications) | 27260700 |
| eCl@ss 7.0 (Classifications) | 27440402 |
| eCl@ss 8.0 (Classifications) | 27440402 |
| eCl@ss 9.0 (Classifications) | 27440402 |
| Range of articles (Dimensions) | MSTBVA 2,5/..-G |
| Nominal current IN (Dimensions) | 12 A |
| Number of positions (Dimensions) | 2 |
| Rated voltage (III/3) (Dimensions) | 250 V |
| Length of the solder pin (Drawings) | 3.9 mm |
| China RoHS (Standards and Regulations) | Environmentally friendly use period: unlimited = EFUP-e |
| Connection in acc. with standard (General) | EN-VDE |
| Connection in acc. with standard (Dimensions) | EN-VDE |
| DiagramType: FKCT 2,5/...-ST with MSTBVA 2,5/...-G (Drawings) | |
| DiagramType: MSTB 2,5/...-ST with MSTBVA 2,5/...-G (Drawings) | |
| DiagramType: MSTBP 2,5/...-ST with MSTBVA 2,5/...-G (Drawings) |
Product Description
Printed circuit board base housing, nominal section: 2.5 mm², color: yellow, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Male, number of potentials: 2, n
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
DiagramType: MSTB 2,5/...-ST with MSTBVA 2,5/...-G
