MSTBA 2,5/ 7-G-RN
MSTBA 2,5/ 7-G-RN 1944835 PHOENIX CONTACT Feed-through header
$0.00USD
4350 in stock
Key Specifications
GTIN:4017918891077
Note:Made to Order (non-returnable)
Orderkey:1944835
(General):CUL
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4017918891077 |
| Note | Made to Order (non-returnable) |
| Orderkey | 1944835 |
| (General) | CUL |
| Catalog page | Page 313 (C-1-2013) |
| Packing unit | 50 pc |
| Country of origin | DE (Germany) |
| Color (Dimensions) | green |
| Custom tariff number | 85366930 |
| Minimum order quantity | 50 pc |
| Pitch (Key Commercial Data) | 5 mm |
| Width (Key Commercial Data) | 40.82 mm |
| (Standards and Regulations) | No hazardous substances above threshold values |
| Height (Key Commercial Data) | 8.6 mm |
| Length (Key Commercial Data) | 12 mm |
| Range of articles (Dimensions) | MSTBA 2,5/..-G-RN |
| Nominal current IN (Dimensions) | 12 A |
| Insulating material (Dimensions) | PBT |
| Number of positions (Dimensions) | 7 |
| Dimension a (Key Commercial Data) | 30 mm |
| Maximum load current (Dimensions) | 12 A |
| Pin spacing (Key Commercial Data) | 5.08 mm |
| Rated voltage (II/2) (Dimensions) | 400 V |
| Width [ w ] (Key Commercial Data) | 40.82 mm |
| Height [ h ] (Key Commercial Data) | 12.1 mm |
| Length [ l ] (Key Commercial Data) | 12 mm |
| Rated voltage (III/2) (Dimensions) | 320 V |
| Rated voltage (III/3) (Dimensions) | 250 V |
| Pin dimensions (Key Commercial Data) | 1 x 1 mm |
| Weight per Piece (excluding packing) | 3.340 g |
| China RoHS (Standards and Regulations) | Environmentally friendly use period: unlimited = EFUP-e |
| Insulating material group (Dimensions) | IIIa |
| Rated surge voltage (II/2) (Dimensions) | 4 kV |
| Rated surge voltage (III/2) (Dimensions) | 4 kV |
| Rated surge voltage (III/3) (Dimensions) | 4 kV |
| Connection in acc. with standard (General) | EN-VDE |
| Connection in acc. with standard (Dimensions) | EN-VDE |
| Length of the solder pin (Key Commercial Data) | 3.5 mm |
| Flammability rating according to UL 94 (General) | V0 |
| Flammability rating according to UL 94 (Dimensions) | V0 |
Product Description
Printed circuit board base case, nominal section: 2.5 mm², color: green, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Male, number of potentials: 7, numbe
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
