MSTB 2,5/ 7-ST-RF BK 2CPPABDWH
MSTB 2,5/ 7-ST-RF BK 2CPPABDWH 1799905 PHOENIX CONTACT Printed-circuit board connector
$0.00USD
4461 in stock
Key Specifications
GTIN:4046356691802
Orderkey:1799905
Packing unit:1
(Connection data):CSA
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4046356691802 |
| Orderkey | 1799905 |
| Packing unit | 1 |
| (Connection data) | CSA |
| Custom tariff number | 85366990 |
| Pitch (Key Commercial Data) | 5 mm |
| (Standards and Regulations) | For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
| Connection method (Dimensions) | Screw connection with tension sleeve |
| Range of articles (Dimensions) | MSTB 2,5/..-ST-RF |
| Nominal current IN (Dimensions) | 12 A |
| Number of positions (Dimensions) | 7 |
| Dimension a (Key Commercial Data) | 30 mm |
| Width [ w ] (Key Commercial Data) | 47.22 mm |
| Height [ h ] (Key Commercial Data) | 15 mm |
| Length [ l ] (Key Commercial Data) | 22.8 mm |
| Nominal cross section (Dimensions) | 2.5 mm² |
| Rated voltage (III/3) (Dimensions) | 250 V |
| China RoHS (Standards and Regulations) | Environmentally Friendly Use Period = 50 |
| Conductor cross section AWG max. (General) | 12 |
| Conductor cross section AWG min. (General) | 24 |
| Conductor cross section solid max. (General) | 2.5 mm² |
| Conductor cross section solid min. (General) | 0.2 mm² |
| Connection in acc. with standard (Dimensions) | EN-VDE |
| Conductor cross section flexible max. (General) | 2.5 mm² |
| Conductor cross section flexible min. (General) | 0.2 mm² |
| Connection in acc. with standard (Connection data) | EN-VDE |
| Conductor cross section flexible, with ferrule with plastic sleeve max. (General) | 2.5 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve min. (General) | 0.25 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve max. (General) | 2.5 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve min. (General) | 0.25 mm² |
Product Description
Printed circuit board connector, nominal section: 2.5 mm2, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Sn, contact connection type: Female, number of potentials: 7, number
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
