MSTB 2,5/ 2-STF BD:+,-
MSTB 2,5/ 2-STF BD:+,- 1713070 PHOENIX CONTACT Printed-circuit board connector
$0.00USD
3921 in stock
Key Specifications
GTIN:4055626404363
Note:Made to Order (non-returnable)
Orderkey:1713070
Packing unit:50 pc
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4055626404363 |
| Note | Made to Order (non-returnable) |
| Orderkey | 1713070 |
| Packing unit | 50 pc |
| Country of origin | DE (Germany) |
| Custom tariff number | 85366990 |
| Minimum order quantity | 50 pc |
| Screw thread (Dimensions) | M3 |
| Pitch (Key Commercial Data) | 5 mm |
| (Standards and Regulations) | For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
| Connection method (Dimensions) | Screw connection with tension sleeve |
| Range of articles (Dimensions) | MSTB 2,5/..-STF |
| Nominal current IN (Dimensions) | 12 A |
| Number of positions (Dimensions) | 2 |
| Dimension a (Key Commercial Data) | 5 mm |
| Width [ w ] (Key Commercial Data) | 20.01 mm |
| Height [ h ] (Key Commercial Data) | 15 mm |
| Length [ l ] (Key Commercial Data) | 18.2 mm |
| Nominal cross section (Dimensions) | 2.5 mm² |
| Rated voltage (III/2) (Dimensions) | 320 V |
| Weight per Piece (excluding packing) | 4.530 g |
| China RoHS (Standards and Regulations) | Environmentally Friendly Use Period = 50 |
| Insulating material group (Dimensions) | I |
| Flammability rating according to UL 94 (General) | V0 |
| Flammability rating according to UL 94 (Dimensions) | V0 |
Product Description
Connector for printed circuit board, nominal section: 2.5 mm², color: green, nominal current: 12 A, dimensioning voltage (III/2): 320 V, contact surface: Tin, contact type: Female connection, Number o
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
