MPM-15-5
MPM-15-5 MEANWELL AC-DC Single output Medical Encapsulated power supply, Output 5VDC / 3A, PCB through hole,..
$0.00USD
4454 in stock
Key Specifications
Name:MPM-15-5
State:New
Format:For Printed Circuit
Series:MPM-15
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | MPM-15-5 |
| State | New |
| Format | For Printed Circuit |
| Series | MPM-15 |
| Approvals | EC, EAC, EN60601 3rd Edition, UL |
| Power (W) | 15,00 |
| Subformato | Encapsulated |
| Width (mm) | 27.20 |
| Height (mm) | 24.00 |
| AC input Max | 264,00 |
| AC input Min | 80,00 |
| Applications | Industrial, Medical, Telecommunications |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Isolation (V) | 4.000,00 |
| Output voltage | 5,00 |
| Peak Power (W) | 16.5 |
| Input connector | Pin |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 52.40 |
| Long Description | Medical power supply for printed circuit board encapsulated.Source certified for medical applications 2x MOPP (patient protection).Encapsulated format for printed circuit boards.Range of universal input80-264vac.47-63Hz.Output voltage5vdc.Output intensity3A(3.3 A max). Range of output current 0-3A according to demand load.Power:15W(16,5 W for 10s).Efficiency typical:85,5%.Consumption without load<0,075 W.Protection against short circuit, over load, over voltage and temperature.Requires No minimum load.Level of vibration up to 5G.Input class II without grounding. EMI class B.Low leakage current < 80µA to 264vac.Working temperature: from-40up+85 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:52,4 x to 27.2 x 24.3 years of warranty.Manufacturer: MEAN WELL.The series MPM are power supply certified for medical use with patient protection, 2 x MOPP (means of patient protection). They have a double protection between input and output 2xMOPP.Have a leakage current (contact current) is very low for a greater security in the application. With low power consumption at no load and requires no minimum load. It has been designed for the most demanding applications at the level of vibration (5G). Sources with class II non-grounded. With an excellent heat dissipation and high useful life thanks to its encapsulation.These sources can be used for medical applications BF (body floating) with the necessary considerations of the system and for industrial applications, and information technology. Suitable for portable medical devices, mobile clinics, monitors and instruments for medical examination. Complies with ANSI/AAMI ES60601-1 and IEC/EN60601-1. |
| Output connector | Pin |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 3,00 |
| Country of Origin | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Medical power supply for printed circuit board encapsulated.
